Sunon SUNON DC-Axiallüfter Serie MB/EB/EE 60x60x25mm Axial fan 12 V 39.9 m³/h (L x W x H) 60 x 60 x 25 mm

Two black fans with multiple rotor blades. One shows the label 'SUNON DC24V', the other shows the rear side of the fan blades.
Product type
Axial fan
Nominal voltage
12 V
No. of wires
2
Power
0.96 W
Type of bearing
Vapo (magnetic)
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
68 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 12.99 / piece)
€ 12.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Sunon fan 12V 60x25 V 39,9m³/h 27dBA

  • Max. 4500 rpm
  • Operating voltage 12 V
  • Max. Air flow 39.9 m³/h
  • This text is machine translated.

Technical specifications

Product type

Axial fan

Type

SUNON DC-Axiallüfter Serie MB/EB/EE 60x60x25mm

Nominal voltage

12 V

No. of wires

2

Min. operating voltage

4.5 V

Max. operating voltage

13.8 V

Operating voltage

4.5 - 13.8 V

Max. current consumption

87 mA

0.96 W

Type of bearing

Vapo (magnetic)

Rotational speed

4500 U/min

Noise emission (max.)

27 dB

Air flow rate

39.9 m³/h

Factory colour

Black

Material

PBT

70000 h

Weight

45 g

Min. temperature

-10 °C

Max. temperature

70 °C

Length

60 mm

Width

60 mm

Height

25 mm

Dim

(L x W x H) 60 x 60 x 25 mm

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2386714 Sunon SUNON DC-Axiallüfter Serie MB/EB/EE 60x60x25mm Axial fan 12 V 39.9 m³/h (L x W x H) 60 x 60 x 25 mm

Description

Hints

Similar to the illustration.
