TE Connectivity RTS3L012 PCB relay 12 V DC 16 A 1 maker 1 pc(s)
Product type
PCB relay
Coil nominal voltage
12 V DC
Control mode
monostable, 1 coil
Contact type
1 maker
Switching voltage (max.)
400 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 3.99 / piece)
€ 3.99
incl. VAT
14-day return policy included
Highlights & Details
Power print relay RT inrush Power, 16 A
Our service for you
Technical specifications
- Product type
PCB relay
- Type
RTS3L012
- Coil nominal voltage
12 V DC
- Min. pick-up voltage
8.4 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
360 Ω
- Contact type
1 maker
- Contact material
AgSnO2
- Switching voltage (max.)
400 V AC
- Switching current (max.)
16 A
- Max. switching capacity
4000 VA
- Creepage distance (coil/clips)
10 mm
- Connection
Solder pins
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
30 mm
- Width
13.7 mm
- Height
25.6 mm
- Dim
(L x W x H) 30 x 13.7 x 25.6 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Nominal voltage (details)
12 V DC
- Nominal current (details)
16 A
- Test voltage
5000 Veff
- Switching capacity
4000 VA
- Type
RTS3L012
- Ambient temperature
-40 - +85 °C
Documents & Downloads
Datasheet
Datasheet 504446 TE Connectivity RTS3L012 PCB relay 12 V DC 16 A 1 maker 1 pc(s)
User & Safety Instructions
User & Safety Instructions 504446 TE Connectivity RTS3L012 PCB relay 12 V DC 16 A 1 maker 1 pc(s)
Description
Anwendungen: Beleuchtungstechnik, Bewegungssensoren, Glüh- and Leuchtstofflampen, Motoren 1 Schließer.
Hints
Approvals: VDE, cULus, CSA.
