TE Connectivity Sensor VCS-02 Float switch 250 V AC 1 A 1 maker, 1 breaker IP65 1 pc(s)
EAN:
Part number:
Item no:
Product type
Float switch
Contact type
1 maker
1 breaker
Material
Polypropylene
Switching voltage
250 V AC
Switching current (max.)
1 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 13.22
3
6% = € 0.73
€ 12.49
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 13.22 / piece)
€ 13.22
plus VAT.
Technical specifications
- Product type
Float switch
- Contact type
1 maker
1 breaker
- Material
Polypropylene
- Connection
Open end cable
- Cable length
10.00 cm
- Switching voltage
250 V AC
- Switching current (max.)
1 A
15 W
- Min. temperature
-30 °C
- Max. temperature
+70 °C
- (Ø)
30 mm
- Thread size
M8
IP65
- Dim
(Ø) 30 mm
- Type
VCS-02
- Material (details)
Glass fibre reinforced PP
- Type
SG 0.64 min floater
- Switching capacity
1 A/250 V AC
- Type
VCS-02
- Connection
0.1 m connection cable 2 x 22 AWG (UL)
- Temperature range
-30 - +70 °C
- Operating voltage
250 V AC
Documents & Downloads
Datasheet
Datasheet 155079 TE Connectivity Sensor VCS-02 Float switch 250 V AC 1 A 1 maker, 1 breaker IP65 1 pc(s)
User & Safety Instructions
User & Safety Instructions 155079 TE Connectivity Sensor VCS-02 Float switch 250 V AC 1 A 1 maker, 1 breaker IP65 1 pc(s)
Certificate
Certificate 155079 TE Connectivity Sensor VCS-02 Float switch 250 V AC 1 A 1 maker, 1 breaker IP65 1 pc(s)
Description
Supplied together with assembly and seal parts for internal attachment, resistant to weakly inorganic acids and bases, alcohol, oils and washing solutions. Choice of make or break function by rotating the float.
