Buy Techno Line WL1040 WL1040 CO2 reading

A digital display shows a CO2 level of 900 ppm, temperature of 21.6 degrees Celsius, and a green field with a 'Good' indicator.

A digital display shows '1500' with CO2 concentration, warning 'MEDIUM' and temperature '21°C 69%'.

Digital clock with CO2 display shows '1980 ppm', marked in red as 'Poor'. Temperature: 21.6°C. Air quality requires improvement.

The image shows a digital display with a CO2 reading of 2100 ppm and a temperature display of 21.6°C. A warning symbol indicates poor air quality.

CO2 meter shows 600 ppm. Bottom right: 'Excellent'. Below: 21°C and 58% humidity. Screen is black and white.

Digital clock shows 12:58, CO2 level 680 ppm, air quality 'Excellent', temperature 21.5°C.

Digital clock showing '12:58', CO₂ level '680 ppm', and temperature display '21°C, 58%'. Air quality rated as 'excellent'.

Digital Clock with CO2 Display: Time '12:58', CO2 level '680 ppm' and temperature '21.5°C', with rating status 'Excellent'.

Digital clock display showing the time '12:58', CO2 level '680 ppm' and humidity '21%', rated as 'Excellent'.

'CO2 Display' shows 5 measurement ranges: 400-600 ppm (excellent), 601-1000 ppm (good), 1001-1500 ppm (moderate), 1501-2000 ppm (poor), over 2000 ppm (very poor).

Digital Clock with CO2 Display Encourages Ventilation with Rising Values. CO2 Status: 'Good Satisfactory', Time: 12:58, Temperature: 21.5°C.

1/13

Fast track dispatch on Wed, 5 Aug

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 147.05 / piece)

€ 147.05

plus VAT.

Only 2 Piece(s) available

Report legal concerns

Highlights & Details

Techno Line WL1040 WL1040 CO2 reading

Air quality sensorNon-dispersive infrared-) gas sensorVentilation recommendedAutomatic background lighting.Air quality sensor

Technical specifications

Product type: CO2 reading

Hub dimensions: 37 x 4 x 16 cm

Display: Digital

Case colour: White

Functions: Inside temperature
Inside CO2

Weight (station): 780 g

Indoor humidity: 20 to 95 %

Reading range - indoor temperature: 0 to 50 °C

Station power supply: Via USB port

CO2 reading range (max.): 5000 ppm

CO2 reading range (min.): 400 ppm

CO2 reading range: 400 – 5000 PPM

Clock face colour: Light red (fluorescent)

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2584017 Techno Line WL1040 WL1040 CO2 reading

Description

CO2 meter / CO2 monitor / CO2 traffic light for continuous monitoring of CO2 concentration (carbon dioxide concentration), indoor temperature and humidity (RH) / measuring method: Single-beam NDIR (non-dispersive infrared technology) Practical CO2 traffic light display (green/yellow/red) with ventilation recommendations for a quick evaluation and interpretation of the current CO2 concentration/autom. CO2 baseline calibration (ABC); also manually calibrated Suitable for example B. Home/apartment owners, schools/lecture halls, offices, hospitals, kindergartens, Public institutions, associations, etc. Individually adjustable upper threshold alarm (visual or acoustic) for CO2 concentration / Acoustic alarm with up to 85 dB volume Power supply is possible via a supplied power unit with a long 1.75 m cable cable feeder / table stand or wall mounting with optional self-adhesive pads

This text is machine translated.

Features

Non-dispersive infrared (NDIR) gas sensor with CO2 measuring range up to 5000 ppmRecommended ventilation based on CO2 content in airRoom temperature display in °C.Indoor humidity displayAdjustable large display of the time (quartz) or of the CO2-measured valueAir quality sensor for monitoring indoor air qualityAdjustable alarm for upper and lower limits of CO2-measured value with optional alarm toneAdjustable alarm for the upper and lower limits of air humidityCalibration function for CO2 measurement valuesIn-built ROM-memory for saving the settingsBacklight with automatic light detection
