WAGO 281-624 N terminal 8 mm Pull spring Configuration: L Grey 50 pc(s) Piece

A grey electrical terminal block with a complex internal structure that enables electrical connection and isolation.
Grey isolated electrical terminal block, 60 mm high and wide.
Technical drawing of a window profile with dimensions: width 73 mm, height 75.5 mm. Details of seals and frame structure visible.
1/3
Packaging type
Piece
Product type
N terminal
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Tue, 12 Jan 2027
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 6.50 / piece)
€ 325.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Disconnect terminal block with movable disconnect slide link

  • 281-624

Technical specifications

  • SI-TRENNKLEMME
Packaging type

Piece

Product type

N terminal

Features

spring-loaded

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

4 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

4 mm²

AWG (min.)

28

AWG max.

12

Clamp width

8 mm

No. of rows

1

Pins per row

2

Number of pins

2

Factory colour

Grey

Nominal current

16 A

Nominal current - rounded value

16 A

Nominal voltage

800 V

Min. stripping length

9 mm

Stripping length (max.)

10 mm

Manufacturer part #

281-624

Content

50 pc(s)

Industrial packaging

Yes

Type

281-624

Dim

(W x H) 8 mm x 60 mm

Width

8 mm

Height

60 mm

Contamination level

3

Connector colour

Grey

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 536540 WAGO 281-624 N terminal 8 mm Pull spring Configuration: L Grey 50 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 536540 WAGO 281-624 N terminal 8 mm Pull spring Configuration: L Grey 50 pc(s) Piece

Description

Grey.
