WAGO 727-228 PD terminal 7.62 mm Pull spring Configuration: L Grey 50 pc(s) Package

Orange row terminal for electrical connections, with multiple connection points and metal contacts, suitable for cross-connections.
Packaging type
Package
Product type
PD terminal
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Wed 18 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 10.70 / piece)
€ 535.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

4-level same potential terminal block

  • 727-228
  • Industrial packaging, pack of 50

Technical specifications

  • 4 LEVEL SAME POTENTIAL TERMINAL LIGH
Packaging type

Package

Product type

PD terminal

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

1.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

1.50 mm²

AWG (min.)

28

AWG max.

16

Clamp width

7.62 mm

No. of rows

4

Pins per row

4

Number of pins

16

Factory colour

Grey

Nominal current

18 A

Nominal current - rounded value

18 A

Nominal voltage

250 V

Min. stripping length

8 mm

Stripping length (max.)

10 mm

Manufacturer part #

727-228

Content

50 pc(s)

Industrial packaging

Yes

Type

727-228

Dim

(W x H) 7.62 mm x 44.50 mm

Width

7.62 mm

Height

44.50 mm

Contamination level

3

Connector colour

Grey

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 542681 WAGO 727-228 PD terminal 7.62 mm Pull spring Configuration: L Grey 50 pc(s) Package

User & Safety Instructions

User & Safety Instructions 542681 WAGO 727-228 PD terminal 7.62 mm Pull spring Configuration: L Grey 50 pc(s) Package

Description

Without latch hook, no label all clamping points are short-circuited, according to EN 60715, light gray.
