WAGO 753-418 PLC digital input module 753-418 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 83.99 / piece)
€ 83.99
incl. VAT
14-day return policy included
Technical specifications
- 2DI 24V DC 3,0ms/Diagn./Acknol.
- Product type
PLC digital input module
- Type
753-418
- No. of digital inputs (max.)
2
- Operating voltage
24 V DC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
753-418
- Weight
40.9 g
- Factory colour
Light grey
- Mounting type
DIN rail
- Inputs / outputs
Inputs: 2
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 192143 WAGO 753-418 PLC digital input module 753-418 1 pc(s)
User & Safety Instructions
User & Safety Instructions 192143 WAGO 753-418 PLC digital input module 753-418 1 pc(s)
Description
24 V DC, 30 ms, positive switch, 2 to 3-conductor connection, acknowledgment, Fault finding, light gray.
This text is machine translated.
This text is machine translated.
Frequently Bought Together
(*All information is plus legal VAT)Total price:
€ 115.47*
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
€ 355.00*
