Buy WAGO 756-9206/040-000 Sensor/actuator connector M12 Plug, right angle No. of pins (RJ): 4 5 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

A rectangular black plug with metal threading and four pins is shown. It is suitable for industrial applications.<br><br>Note: The translation is in British English, maintaining the original meaning and technical description.

A rectangular black plug with metal threading and four pins is shown. It is suitable for industrial applications.<br><br>Note: The translation is in British English, maintaining the original meaning and technical description.

Two circular diagrams with four numbers, 1 to 4. Left diagram: Numbers in a clockwise direction. Right diagram has number 5 in the centre.

'Connectable cable: Ø 6 ... 8 mm. Screw technology: 0.25 ... 0.75 mm². Spring technology: 0.14 ... 0.5 mm².'

Technical drawing of an angled connector with dimensions: Length 40 mm, Height 41 mm, Connection PG9, Thread M12 with Ø 20.2 mm.

1/4

WAGO

Product type

Sensor/actuator connector

Connector type

Plug, right angle

Connector standard

Sensor connector

Connection side A

M12 plug, right angle

Connection side B

Customisable

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 14 Dec

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 5 pc(s))

Set(s)

Total (€ 15.60 / piece)

€ 77.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Connectors for sensor/actuator cable

756-9206/040-000
Industrial packaging with 5 pieces

Technical specifications

M12 ST WINKL 4-POL SCHRAUB PG9

Type: 756-9206/040-000

Product type: Sensor/actuator connector

Connector type: Plug, right angle

Connector standard: Sensor connector

Connection side A: M12 plug, right angle

Connection side B: Customisable

No. of pins: 4

Nominal voltage: 250 V

Nominal current: 4 A

Nominal current - rounded value: 4 A

Connection: Screw terminal

Factory colour: Black

Thread type connection side: M12

max. cross section: 0.25 mm²

Min. cross section: 0.25 mm²

Seal type: Screw-on

Manufacturer part #: 756-9206/040-000

Industrial packaging: Yes

Content: 5 pc(s)

Cable diameter (details): 6 mm

Documents & Downloads

Datasheet

Datasheet 546606 WAGO 756-9206/040-000 Sensor/actuator connector M12 Plug, right angle No. of pins (RJ): 4 5 pc(s)

User & Safety Instructions

User & Safety Instructions 546606 WAGO 756-9206/040-000 Sensor/actuator connector M12 Plug, right angle No. of pins (RJ): 4 5 pc(s)

Description

4-pin, M12 plug, angled.

This text is machine translated.

Description

4-pin, M12 plug, angled.

This text is machine translated.
