Name: ABB 2CSF204123R1630 F204A-63/0,03L RCCB A 4-pin 63 A 0.03 A 230 V
Brand: ABB
SKU: 1826896
Availability: InStock

Product type

RCCB

Number of pins

Release characteristics

Differential current rating

0.03 A

Nominal current - rounded value

63 A

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 4 Nov

9 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 124.99 / piece)

€ 124.99

incl. VAT

Only 9 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

ABB Residual current circuit breaker F 204 A -63/0. 03 L 4-pin

Measured residual current 30 mA
Nominal current (in) 63 A
Number of pins 4

Technical specifications

Product type: RCCB

Number of pins: 4

Release characteristics: A

Differential current rating: 0.03 A

Nominal current: 63 A

Nominal current - rounded value: 63 A

Dim: (W x H x D) 70 x 85 x 69 mm

Content: 1 pc(s)

Nominal voltage: 230 V

Width: 70 mm

Height: 85 mm

Depth: 69 mm

Nominal voltage (details): 230 - 400 V

Weight: 0

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1826896 ABB 2CSF204123R1630 F204A-63/0,03L RCCB A 4-pin 63 A 0.03 A 230 V

User & Safety Instructions

User & Safety Instructions 1826896 ABB 2CSF204123R1630 F204A-63/0,03L RCCB A 4-pin 63 A 0.03 A 230 V

Description

Residual current circuit breakers (RCCs) provide personal protection and property protection as well as protection from electrical fires according to DIN VDE 0100-410 and DIN VDE 0100-530. The residual current circuit-breakers of series F200 ensure protection in case of sinusoidal AC currents and pulsating currents with a smooth DC-fault share of up to 6 mA against earth. Fault protection (protection in case of indirect contact), additional protection (with IΔn ≤ 30 mA) and fire protection (with IΔn ≤ 300 mA). They meet the product standards IEC/EN 61008-1, 61008-2-1, 61543 (VDE 0664 10, 11, 30) and for F200 A up to 100 A UL 1053. They are used in domestic, commercial and industrial applications. The extensive range of accessories offers you everything that you need WAS for your installation tasks. Numerous approvals make the F200 ready for worldwide use.
F200 A type A with left-hand neutral conductor connection
(N conductor required on left or 3-phase network without N conductor)

This text is machine translated.
