Buy AccuLux HL 30 EX POWER Set Torch Ex Zoning: 1, 2, 21, 22 420 lm 250 m

Yellow and black handheld device with a round 10x lens and digital display, shown beside its charging dock on a white background.

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 449.58 / piece)

€ 449.58

plus VAT.

Only 2 Piece(s) available

Report legal concerns

Highlights & Details

The snap head lamp for firefighters

Ex-protected LED hand lamp permanently charged in the charging station
Up to 420 lumens for close and distant range
Protection class IP67
Ex-zones 1, 2, 21, 22
Made in Germany

Technical specifications

Product type: Torch

Ex Zoning: 1
2
21
22

Factory colour: Yellow/Black

Dim: (L x W x H) 77 x 105 x 237 mm

LEDs: 2

Operating voltage: 12 V DC
24 V DC
230 V AC

Weight: 580 g

Bulb type: LED (monochrome)

Illumination range (high): 250 m

Luminous flux (range): 200 lm - 499.9 lm

Luminous flux (high): 420 lm

Total luminous flux: 420 lm

Material: Plastic

Width: 105 mm

Height: 237 mm

Length: 77 mm

: IP67

Power supply (LOV): rechargeable

Temperature range: Ambient temperature -20 °C to +40 °C. °C

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3815029 AccuLux HL 30 EX POWER Set Torch Ex Zoning: 1, 2, 21, 22 420 lm 250 m

User & Safety Instructions

User & Safety Instructions 3815029 AccuLux HL 30 EX POWER Set Torch Ex Zoning: 1, 2, 21, 22 420 lm 250 m

Description

AccuLux HL 30 EX Power is a microprocessor-controlled, chargeable safety inspection lamp, which is tested according to ATEX directive 2014/34/EU and relevant EMC regulations. The lamp is equipped with two switchable high-power LEDs, which deliver up to 420 lumens in three switching stages. The lithium-ion rechargeable battery is protected against total discharge by intelligent circuit layout, can be trickle charged and can be changed by the user himself. The light can be set flexibly due to the 180° degree swiveling lamp head. The handy rotary switch (easy to use even with thick gloves) and the minute-accurate digital display of the battery remaining time makes working with the HL 30 EX Power even simpler and safer. With an approval for EX zones 1, 2, 21 and 22, it is a reliable companion for hazardous areas.

This text is machine translated.
