Arnold Rak Set 6101-20 Heater cable 230 V 200 W 10 m
EAN:
Part number:
Item no:
Number
Total (€ 70.58 / piece)
€ 130.25
-46 %
€ 70.58
plus VAT.
Only 3 Piece(s) available
Highlights & Details
Electric Floor Heating Cable 200W
- IPX7
- 10 years warranty
Technical specifications
- Product type
Heater cable
- Operating voltage
230 V
- Heating element length
10 m
- W/m
20 W
200 W
- Installation
Indoor
Outdoor
- Frost protection
No
- Lead length
3 m
- Factory colour
Black
IPX7
- Operating voltage
230 V/50 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 566005 Arnold Rak Set 6101-20 Heater cable 230 V 200 W 10 m
Warranty Terms
Warranty Terms 566005 Arnold Rak Set 6101-20 Heater cable 230 V 200 W 10 m
Description
Floor-heating cable in twin design,outward and return conductor produce heating. By heating in both directions, to heat both the conductors a specific wattage of heating conductor is distributed per meter.It gives optimal heat distribution and longer life and each heating elements are claimed with half the power. This heating cable is laid suitably under all the floors covering every conceivable space. Transfer, pass,distance of heating cable determines the amount of heat per m² and the deployable space. Heating cable with 20 W / m is suitable for areas with increased demand for heat.For example, Sunrooms, basements, entrance, covered outdoor areas. Complies with DIN EN 60335-1, DIN EN 60335-2-96 and EN 50366th
Features
- 3 m connection cable (permanently attached).
Scope of delivery
- Heating cables including double-sided fabric tape, warranty card and installation instructions.
Hints
Not for embedding in mastic asphalt or reinforced concrete.
