Buy Blickle 280172 B-VE 160R Fixed wheel Wheel diameter: 160 mm Load capacity (max.): 135 kg 1 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Industrial double wheel with robust metal housing, black rubber wheel and inscription 'Blickle made in Germany'. Suitable for heavy loads.

Industrial double wheel with robust metal housing, black rubber wheel and inscription 'Blickle made in Germany'. Suitable for heavy loads.

Blickle

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 11 Nov

10 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 19.99 / piece)

€ 19.99

incl. VAT

Only 10 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

steel sheet-Bockrolle, Ø 160 mm

Roller bearing
fully rubberised wheels;

Technical specifications

Product type: Fixed wheel

Wheel Ø: 160 mm

Load capacity (max.): 135 kg

Features: Mount

Total height: 195 mm

Size: 140 x 110 mm

Wheel width: 40 mm

Bearing type: Roller bearing

Material: Solid rubber

Factory colour: Black

Content: 1 pc(s)

Hole distance: 105 x 75-80 mm

Material (details): Full-rubber tyres, casing made of galvanised sheet steel

Type: Castor

Tyre width: 40 mm

Documents & Downloads

Datasheet

Datasheet 826733 Blickle 280172 B-VE 160R Fixed wheel Wheel diameter: 160 mm Load capacity (max.): 135 kg 1 pc(s)

Datasheet 826733 Blickle 280172 B-VE 160R Fixed wheel Wheel diameter: 160 mm Load capacity (max.): 135 kg 1 pc(s)

User & Safety Instructions

User & Safety Instructions 826733 Blickle 280172 B-VE 160R Fixed wheel Wheel diameter: 160 mm Load capacity (max.): 135 kg 1 pc(s)

Description

Steel sheet fixed roller, medium heavy construction, with mounting plate,
Wheel with standard solid rubber tires, with steel plate rim

Housing: Series B

• Sheet steel, galvanized, blue passivated, Cr6-free

Wheel: Series VE

• Tyres: Standard solid rubber, hardness 80 shore A, color black
• Rim: Steel plate, pressed, galvanized electrically, blue passivated, Cr6-free

Other properties:

• Chemical resistance to many aggressive media, but not to oils
• Temperature resistance: -25 °C to +80 °C, reduced load capacity above +60 °C.

This text is machine translated.

Features

Case with double ball bearings in rotating assembly
Axle is firmly screwed down, galvanised - chrome-plated
Wheel with standard solid rubber tyres
Rim pressed out of sheet metal
Roller bearing.

Description

Steel sheet fixed roller, medium heavy construction, with mounting plate,
Wheel with standard solid rubber tires, with steel plate rim

Housing: Series B

• Sheet steel, galvanized, blue passivated, Cr6-free

Wheel: Series VE

• Tyres: Standard solid rubber, hardness 80 shore A, color black
• Rim: Steel plate, pressed, galvanized electrically, blue passivated, Cr6-free

Other properties:

• Chemical resistance to many aggressive media, but not to oils
• Temperature resistance: -25 °C to +80 °C, reduced load capacity above +60 °C.

This text is machine translated.

Features

Case with double ball bearings in rotating assembly
Axle is firmly screwed down, galvanised - chrome-plated
Wheel with standard solid rubber tyres
Rim pressed out of sheet metal
Roller bearing.
