Name: DISPLAY VISIONS OLED screen (W x H x D) 36.9 x 41.2 x 2.1 mm
Brand: DISPLAY VISIONS
SKU: 2291101
Availability: InStock

Dial of a circular instrument with a scale from 0 to 1.5. The pointer is indicating 0. Below it reads 'bar BOOST'.

Product type

OLED screen

Lighting type

OLED

Height

41.2 mm

Width

36.9 mm

Light area (width)

30 mm

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 59.99 / piece)

€ 59.99

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Our service for you

Technical specifications

Product type: OLED screen

Light area (width): 30 mm

Light area (height): 30 mm

Lighting type: OLED

Type (display): OLED

Operating voltage: 2.70 - 3.30 V DC

Max. current consumption: 24 mA

Dim: (W x H x D) 36.9 x 41.2 x 2.1 mm

Depth: 2.1 mm

Height: 41.2 mm

Width: 36.9 mm

Min. operating voltage: 2.70 V DC

Max. operating voltage: 3.30 V DC

RoHS-compliant: Yes

Max. temperature: 80 °C

Min. temperature: -40 °C

Variants(All information include VAT, plus shipping costs)

Dim

Height

Lighting type

Width

DISPLAY VISIONS OLED screen (W x H x D) 36.9 x 41.2 x 2.1 mm

Item no:2291101

Fast track dispatch on Thu 29 Oct

1 Piece(s)Conrad Electronic

This article

(W x H x D) 36.9 x 41.2 x 2.1 mm

41.2 mm

OLED

36.9 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 59.99^*

DISPLAY VISIONS OLED screen (W x H x D) 29.1 x 9.2 x 1.45 mm

Item no:2291096

Dispatches on Fri 30 Oct

10 Piece(s)Conrad Electronic

(W x H x D) 29.1 x 9.2 x 1.45 mm

9.2 mm

29.1 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 13.99^*

DISPLAY VISIONS OLED screen (W x H x D) 36.9 x 41.2 x 2.1 mm

Item no:2291099

Fast track dispatch on Thu 29 Oct

4 Piece(s)Conrad Electronic

(W x H x D) 36.9 x 41.2 x 2.1 mm

41.2 mm

OLED

36.9 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 65.99^*

DISPLAY VISIONS OLED screen (W x H x D) 55 x 43 x 3.3 mm

Item no:2291048

Dispatches on Fri 30 Oct

63 Piece(s)Conrad Electronic

(W x H x D) 55 x 43 x 3.3 mm

43 mm

55 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 59.99^*

DISPLAY VISIONS OLED screen (W x H x D) 68 x 51 x 2.1 mm

Item no:2291078

Dispatches on Fri 30 Oct

8 Piece(s)Conrad Electronic

(W x H x D) 68 x 51 x 2.1 mm

51 mm

OLED

68 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 61.99^*

DISPLAY VISIONS OLED screen (W x H x D) 68 x 51 x 3.3 mm

Item no:2291066

Dispatches on Fri 30 Oct

5 Piece(s)Conrad Electronic

(W x H x D) 68 x 51 x 3.3 mm

51 mm

OLED

68 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 57.99^*

DISPLAY VISIONS OLED screen (W x H x D) 88 x 27.8 x 2.05 mm

Item no:2291112

Fast track dispatch on Thu 29 Oct

2 Piece(s)Conrad Electronic

(W x H x D) 88 x 27.8 x 2.05 mm

27.8 mm

88 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 42.99^*

DISPLAY VISIONS OLED screen 128 x 64 Pixel (W x H x D) 60.5 x 37 x 2.15 mm

Item no:2291052

Fast track dispatch on Thu 29 Oct

2 Piece(s)Conrad Electronic

(W x H x D) 60.5 x 37 x 2.15 mm

37 mm

60.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 65.99^*

DISPLAY VISIONS OLED screen 128 x 64 Pixel (W x H x D) 68 x 51 x 2.1 mm

Item no:2291084

Fast track dispatch on Thu 29 Oct

2 Piece(s)Conrad Electronic

(W x H x D) 68 x 51 x 2.1 mm

51 mm

OLED

68 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 40.99^*

DISPLAY VISIONS OLED screen Yellow (W x H x D) 33.8 x 36.5 x 2.05 mm

Item no:2291073

Fast track dispatch on Thu 29 Oct

5 Piece(s)Conrad Electronic

(W x H x D) 33.8 x 36.5 x 2.05 mm

36.5 mm

OLED

33.8 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 45.99^*

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2291101 DISPLAY VISIONS OLED screen (W x H x D) 36.9 x 41.2 x 2.1 mm

Description

Round OLED in white with 30mm diameter (active range). Extremely wide temperature range and fast display (type. 10µs also at -40°C). The display offers a wide viewing angle of almost 180°. The display can be easily contacted via the 24-pin flexible connection.
The SPI, I²C and parallel 8-bit are available as interfaces.

This text is machine translated.
