Eberle 547895554502 UTE 2500-RAL9010-G-55 Indoor thermostat Flush mount 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 57.99 / piece)
€ 57.99
incl. VAT
14-day return policy included
Highlights & Details
EBERLE UTE 2500-RAL9010-G-55 UP-ROOM CONTROLLER
- FLUSH-MOUNTED ROOM CONTROLLER, 5 - 30 C, 230 V ACContact-free output by means of triacSwitchable 5 actuators a 3 WChange-over input, TA 3.5 K.
Technical specifications
- Product type
Indoor thermostat
- Operation type
electronical
- Max. temperature setting
30 °C
- Temperature settings
5 up to 30 °C
- Frost protection
Yes
- Display
No
- Remote sensor
No
- Compatible with
Underfloor heating
- Mounting type
Flush mount
- Power supply (LOV)
mains-powered
- Operating voltage
230 V
- Nighttime drop
Yes
- Factory colour
Polar white glossy
- Similar RAL
9010
- Width
55 mm
- Height
55 mm
- Length
55 mm
not cloud-enabled
IP30
- Dim
(L x W x H) 55 x 55 x 55 mm
- Weight
60 g
- Contact type
Triac
- Min. temperature setting
5 °C
- Depth
17 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2559386 Eberle 547895554502 UTE 2500-RAL9010-G-55 Indoor thermostat Flush mount 1 pc(s)
Description
Electronic flush-mounted room temperature controller for controlling or monitoring temperatures in living rooms, offices and hotels. Suitable for all common switch programs. Polar white glossy, 55x55 cover with button. Suitable for water-guided heating systems. By using a triac switch completely noiseless, in contrast to relays or bimetallic. Can be switched automatically through a change-over input, therefore can be used for heating and cooling. When the watch clamp is connected, the temperature is regulated to a lower temperature by 3.5K and increased by 3.5K in cooling mode. With LED status indicators. Adjustable range restriction in the adjustment knob as heating cost brake. A captive screw with threaded insert to secure the housing cover and convenient plug-in terminals make it easy to install. Mounting in 55er flush-mounted socket.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Controller subcleaning insert
- Regulator cover
- Setpoint control button
- User manual.
