econ connect SMA10FG SMA10FG SMA connector Socket 50 Ω 1 pc(s)

Two gold-coloured metal connector plugs, standing side by side. They each have two pins and ridged housing caps.
Technical drawing of a plug with dimensions in millimetres, e.g. length 13.5 and 9.5 diameter. Recommended mounting holes shown.
1/2
Product type
SMA connector
Connector type
Socket
Impedance
50 Ω
Connection
Solder pins
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Wed 11 Nov
118 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 4.29 / piece)
€ 4.29
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

SMA connectors

  • The plug socket - name, according to the shape of the inner conductor defined.
  • This text is machine translated.

Our service for you

Technical specifications

Product type

SMA connector

Connector type

Socket

Impedance

50 Ω

Connection

Solder pins

Content

1 pc(s)

Case material

Brass gold plated

Manufacturer part #

SMA10FG

Insulation resistance

5000 MOHM

Insulation material

PTFE

Contact material

Brass gold plated

RoHS-compliant

Yes

Type

SMA10FG

Seal type

Screw-on

Documents & Downloads

Datasheet

Datasheet 1311505 econ connect SMA10FG SMA10FG SMA connector Socket 50 Ω 1 pc(s)
