Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 30.24
3
4% = € 1.18
€ 29.06
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 30.24 / piece)
€ 36.97
-18 %
€ 30.24
plus VAT.
Only 7 Piece(s) available
Highlights & Details
LED-Dimmer 7-110 W
Technical specifications
- Product type
Flush-mount dimmer
- Operating voltage
230 V
- Power rating (min.)
3 W
- Suitable for
Transformer (mechanical)
- Power rating (max.)
110 W
- Suitable for light bulbs
Energy saving bulb
LED bulb
Halogen lamp
Light bulb
- Switching capacity (LED)
3 - 35 W
- Switching capacity (energy saving bulbs)
7 - 110 W
- Switching capacity (light bulbs)
7 - 110 W
- Switching capacity (halogen bulbs)
7 - 110 W
- Shaft Ø
4 mm
- Dim
(W x H) 71 mm x 33 mm
- Width
71 mm
- Height
33 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1385952 Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
User & Safety Instructions 1385952 Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
Information
Information 1385952 Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
Conformity certificate
Conformity certificate 1385952 Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
Warranty Terms
Warranty Terms 1385952 Ehmann 3900x0700 Flush-mount dimmer Suitable for light bulbs: Energy saving bulb, LED bulb, Halogen lamp, Light bulb
Description
LUMEO ECO UP phase control dimmer, R, L, 7-110 W/VA, LED 3-35W, for dimmable LEDs. HV/LV halogen with magnetic transformer. Pressure-change switch, Ø 4 mm metal shaft with fine grating. Adjustable minimum brightness. Screw terminals up to 2 x 2.5 mm², with fine-wire fuse
With metal carrier plate.
This text is machine translated.
With metal carrier plate.
This text is machine translated.
Scope of delivery
- Incl. Shaft adapter 6 mm.
Hints
The part stored by the QR code to get to a LED lamp recommendation list, on the exactly, for which this LED bulb dimmer is suitable.
