Ehmann 5500x0100 Rotary dimmer Suitable for light bulbs: LED bulb, Halogen lamp, Light bulb

1/3
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct

11 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions

Number
Total (€ 55.99 / piece)
€ 55.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included

Highlights & Details

LED universal dimmer T55.01

  • Rotary dimmer with push-change switch
  • Suitable for dimmable LEDs, LED driver, filament LEDs, glow and HV and LV halogen lamps
  • Close-up of a green electronic control panel with a black button labelled 'SET', and the options 'ON/OFF' and 'MIN/MAX'.
  • The image shows the TÜV logo with the inscription 'EMC tested', indicating a successful examination by SGS TÜV Saarland.

Technical specifications

Product type

Rotary dimmer

Power rating (min.)

3 W

Power rating (max.)

220 W

Suitable for light bulbs

LED bulb

Halogen lamp

Light bulb

Switching capacity (LED)

100 W

Switching capacity (light bulbs)

220 W

Switching capacity (halogen bulbs)

circuit resistance 220 W

Shaft Ø

4 mm

Documents & Downloads

Datasheet

Datasheet 2202166 Ehmann 5500x0100 Rotary dimmer Suitable for light bulbs: LED bulb, Halogen lamp, Light bulb

User & Safety Instructions

User & Safety Instructions 2202166 Ehmann 5500x0100 Rotary dimmer Suitable for light bulbs: LED bulb, Halogen lamp, Light bulb

Information

Information 2202166 Ehmann 5500x0100 Rotary dimmer Suitable for light bulbs: LED bulb, Halogen lamp, Light bulb

Description

LED dimmer from the 3rd Generation – unique in its performance and combination of performance, ease of use, reliability, sustainability and LED compatibility. The perfect dimming procedure / working principle can be determined independantly depending on the LED used. By manually selecting the dimming principle as well as other features and setting options, the universal LED dimmer T55.01 reliably dims almost all LEDs - independant of the manufacturer and type of LED. This makes it compatible with all LED types, such as retrofit and filament LEDs and LED drivers. The ISO-gate® technology developed by EHMANN is based on the interaction of the newly developed DIMM and trigger software in combination with high-quality and partly newly developed performance components. This provides for a maximum power spectrum and the highest possible LED compatibility. Integrated, easy to handle setting of the min. and max. brightness as an optimization possibility for flicker-free dimming. Compatible with switch programs (covers) of e.g. Busch-Jäger, Gira, Berker, Jung, Kopp etc. Through the Silent Technology, the dimmer works absolutely noiseless and thanks to the real on/off switch, the dimmer does not generate standby consumption.

This text is machine translated.

Features

  • For all dimmable LED lamps and LED drivers, incandescent/halogen lamps
  • LED universal dimmer with ISO-gate® technology – for a maximum power spectrum (up to 400W) and LED compatibility
  • Silent Technology – absolutely noiseless mode of operation
  • freely selectable setting of the dimming principle (phase angle or phase section), Manually switchable
  • electronic short-circuit and overload protection and over-temperature protection with automatic reactivation
  • No standby consumption by real on/off switch
  • compatible with switch programs of Busch-Jäger, Gira, Berker, Jung and much more.
  • Actuation: Rotary dimmer with push-change switch
  • Shaft: Ø 4 mm metal with soft grid (Ø 6 mm with shaft adapter)
  • Connection: Screw terminals up to 2 x 2.5 mm² (rigid)
  • Overtemperature protection: Self-resetting temperature switch
  • Short circuit/overload protection: Electronic

Scope of delivery

  • Dimmer insert
  • Switch program adapter
  • User manual.

Hints

Safety note: Work on the 230 V mains may only be carried out by an electrician, taking into account the valid regulations (e.g. DIN VDE). All activities may only be carried out if the mains voltage is switched off. Failure to observe the installation instructions can result in damage to the device, fire or other hazards.
