Name: Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)
Brand: Ehmann
SKU: 702399
Availability: InStock

A black, rectangular electronic device with a sliding control and dotted details, possibly a control unit.

Yellow sign with white circle and repair icon; text: '5 Years' and 'REPAIR SERVICE'.

1/2

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

6 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 43.36 / piece)

€ 43.36

incl. VAT

Only 6 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

NV-Halogen lamps leading edge cord dimmer

Separate on/off switch
Sliding controller for manual and foot operation
With orientation light
No standby consumption

Technical specifications

Actuation: sliders and switches
Control: phase angle control
Suitable for: 230 V halogen lamps, NV-Halogen lamps with wound transformers

Product type: Pull dimmer

Factory colour: Black

Length: 130 mm

Width: 60 mm

Height: 35 mm

Dim: (L x W x H) 130 x 60 x 35 mm

Min. switching capacity: 20 W

Max. switching capacity: 500 W

Switching voltage: 230 V AC

Content: 1 pc(s)

Type: LUMEO MOBIL

Documents & Downloads

Datasheet

Datasheet 702399 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)

User & Safety Instructions

User & Safety Instructions 702399 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)

Description

Complete device for NV-Halogen lamps (with magnetic transformers), HV-Halogen lamps and bulbs The device has an in-built micro fuse, which can be changed, if necessary The required brightness can be adjusted via the sliding control; the device is switched on and off at the separate switch, without changing the background brightness. The orientation light on the device makes it easier to locate in the dark. With the various ways to connect the cord dimmer can be used alternatively as an intermediate or terminal.
