Elobau 20101C01-1

A white float switch with a grey cable, used for monitoring liquid levels. Primarily employed in water tanks.
Elobau 20101C01-1-1
Elobau 20101C01-1-2
1/3
Image similar
Product type
Float switch
Contact type
1 maker
Material
Polyamide
Switching voltage
200 V DC
250 V AC
Switching current (max.)
1 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
49 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 25.20 / piece)
€ 25.20
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Elobau 20101C01-1

Our service for you

Technical specifications

Product type

Float switch

Contact type

1 maker

Material

Polyamide

Connection

Open end cable

Cable length

1.00 m

Switching voltage

200 V DC

250 V AC

Switching current (max.)

1 A

50 W

50 VA

Min. temperature

-25 °C

Max. temperature

+100 °C

Thread size

G3/8"

Recess diameter

16.7 mm

IP67

RoHS-compliant

Yes

Type

20101C01-1

Documents & Downloads

Datasheet

Datasheet 709969 Elobau 20101C01-1

Information

Information 709969 Elobau 20101C01-1

Description

Resistant to weak inorganic acids, alkalis, alcohol or oils. Switching function can be changed by turning the float.
