Elobau 221B1710 Float switch 48 V 1 A 1 change-over IP67 1 pc(s)
EAN:
Part number:
Item no:
Product type
Float switch
Contact type
1 change-over
Material
Brass
Switching voltage
48 V
Switching current (max.)
1 A
Datasheet (PDF)
17 Piece(s)
Sales and shipping:
Number
Total (€ 69.48 / piece)
€
Technical specifications
- Installation depth 220 mm
- Product type
Float switch
- Contact type
1 change-over
- Material
Brass
- Connection
Open end cable
- Cable length
1.00 m
- Switching voltage
48 V
- Switching current (max.)
1 A
20 W
- Min. temperature
-30 °C
- Max. temperature
+100 °C
- Thread size
G3/8"
IP67
- RoHS-compliant
Yes
- Type
221B1710
Documents & Downloads
Datasheet
Datasheet 709995 Elobau 221B1710 Float switch 48 V 1 A 1 change-over IP67 1 pc(s)
Information
Information 709995 Elobau 221B1710 Float switch 48 V 1 A 1 change-over IP67 1 pc(s)
Description
Filling Level meter for vertical installation and 2 switching points. Resistant to weak inorganic acids, alkalis, alcohol or oils.
