Feed-through terminal block ST 16 BU 3036152 Phoenix Contact

A blue terminal block with vertical rows of connection points for electrical wires, commonly used in electrical control cabinets.
Packaging type
Piece
Product type
Serial continuity
Connection
Pull spring
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
25 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 30 Oct
20 Set(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 3.80 / piece)
€ 189.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Packaging type

Piece

Product type

Serial continuity

Connection

Pull spring

Cross section (flexible) (min.)

0.2 mm²

Cross section (flexible) (max.)

16 mm²

Cross section (inflexible) (min.)

0.2 mm²

Cross section (inflexible) (max.)

25 mm²

AWG (min.)

24

AWG max.

6

Clamp width

12.2 mm

No. of rows

1

Number of pins

2

Factory colour

Blue

Nominal current

76 A

Nominal current - rounded value

76 A

Nominal voltage

1000 V

Stripping length (max.)

18 mm

Manufacturer part #

3036152

Content

50 pc(s)

Industrial packaging

Yes

Type

ST 16 BU

Dim

(L x W x H) 80 x 12.2 x 51.5 mm

Width

12.2 mm

Height

51.5 mm

Length

80 mm

Contamination level

3

Flammability rating

V0

Connector colour

Blue

Insulation material

PA

Insulation

PA

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 565525 Feed-through terminal block ST 16 BU 3036152 Phoenix Contact

User & Safety Instructions

User & Safety Instructions 565525 Feed-through terminal block ST 16 BU 3036152 Phoenix Contact

Description

Feed-through terminal block, Connection method: Spring-cage connection, Cross section: 0.2 mm² - 25 mm², AWG: 24 - 4, Width: 12.2 mm, Color: blue, Mounting type: NS 35/7,5, NS 35/15
