Name: FESTO Magnetic valve 6211 MFH-5-1/4 G 1/4 Nominal width (details) 7 mm 1 pc(s)
Brand: FESTO
SKU: 1894342
Availability: InStock

A rectangular pneumatic cylinder with two ports and multiple screw holes, suitable for industrial applications.

Datasheet (PDF)

2 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 209.99 / piece)

€ 209.99

incl. VAT

Only 2 Piece(s) available

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Magnetic valve MFH-5-1/4

Technical specifications

Product type: Magnetic valve

Max. operating pressure: 8 bar

Enclosure material: Aluminium (die-cast)

Connection: G 1/4

Operating medium: According to ISO 8573-1:2010 compressed air [7:4:4]

Media temperature (range): -10 up to +60 °C

Manufacturer part #: 6211

Operating pressure (min.): 2.2 bar

Operation: Electrically

Sealant: NBR

Max. flow: 1000 l/min

Function: 5/2-way

Weight: 290 g

Max. media temperature: +60 °C

Media temperature (min.): -10 °C

Nominal width: 7 mm

Features: P port connector (G1/4)

: IP65

Max. ambient temperature: +40 °C

Min. ambient temperature: -5 °C

UKCA: not relevant

Variants(All information include VAT, plus shipping costs)

Connection

Max. operating pressure

Enclosure material

FESTO Magnetic valve 10348 MFH-5-1/8-S G 1/8 Nominal width (details) 5 mm 1 pc(s)

Item no:1894417

Dispatches on Thu 22 Oct

Conrad Electronic

G 1/8

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 189.99^*

FESTO Magnetic valve 10349 MFH-5-1/4-S G 1/4 Nominal width (details) 7 mm 1 pc(s)

Item no:1896286

Dispatches on Thu 22 Oct

Conrad Electronic

G 1/4

8 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 214.99^*

FESTO Magnetic valve 11121 MFH-3-1/8-SEU G 1/8 1 pc(s)

Item no:2804120

Dispatches on Tue 27 Oct

Conrad Electronic

G 1/8

8 bar

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 189.99^*

FESTO Magnetic valve 11546 MFH-5-PK-3-L PK-3 Nominal width (details) 2.5 mm 1 pc(s)

Item no:1895439

Dispatches on Thu 22 Oct

Conrad Electronic

PK-3

8 bar

Aluminium

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 305.00^*

FESTO Magnetic valve 11967 MFH-3-3/4 G 3/4 Nominal width (details) 19 mm 1 pc(s)

Item no:1896436

Dispatches on Thu 22 Oct

Conrad Electronic

G 3/4

8 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 579.00^*

FESTO Magnetic valve 11968 MFH-3-3/4-S G 3/4 Nominal width (details) 19 mm 1 pc(s)

Item no:1896721

Dispatches on Thu 22 Oct

Conrad Electronic

G 3/4

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 585.00^*

FESTO Magnetic valve 150981 MFH-5/2-D-1-C Connector plate Nominal width (details) 8 mm 1 pc(s)

Item no:1896756

Dispatches on Thu 22 Oct

Conrad Electronic

Connector plate

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 154.99^*

FESTO Magnetic valve 150982 MFH-5/3G-D-1-C Connector plate Nominal width (details) 8 mm 1 pc(s)

Item no:1894575

Dispatches on Thu 22 Oct

Conrad Electronic

Connector plate

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 269.00^*

FESTO Magnetic valve 150983 MFH-5/3E-D-1-C Connector plate Nominal width (details) 8 mm 1 pc(s)

Item no:1895253

Dispatches on Thu 22 Oct

Conrad Electronic

Connector plate

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 269.00^*

FESTO Magnetic valve 150984 MFH-5/3B-D-1-C Connector plate Nominal width (details) 8 mm 1 pc(s)

Item no:1896457

Dispatches on Thu 22 Oct

Conrad Electronic

Connector plate

10 bar

Aluminium (die-cast)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 269.00^*

Documents & Downloads

Datasheet

Datasheet 1894342 FESTO Magnetic valve 6211 MFH-5-1/4 G 1/4 Nominal width (details) 7 mm 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1894342 FESTO Magnetic valve 6211 MFH-5-1/4 G 1/4 Nominal width (details) 7 mm 1 pc(s)

Information

Information 1894342 FESTO Magnetic valve 6211 MFH-5-1/4 G 1/4 Nominal width (details) 7 mm 1 pc(s)

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
