Name: FESTO Wheel lever valve R-3-M5 3629 -0.95 up to 8 bar External thread M5 1 pc(s)
Brand: FESTO
SKU: 2115111
Availability: BackOrder

Black, rectangular metal object with a hinge at the top and three screw holes on the side. Used for fastening or connecting.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 95.99 / piece)

€ 95.99

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

Valve function: 3/2 closed mono-stable
Nominal width: 2mm
Operating method: mechanical
Ambient temperature: -10 °C to +60 °C
Product weight: 40g
Material Seals: NBR
Actuating force 16.5 N
Normal nominal flow rate: 80 l/min

Operating medium: According to ISO 8573-1:2010 [compressed air -:-:-]

Product type: Wheel lever valve

External thread: M5

Min. display range: -0.95 bar

Display range (max.): 8 bar

Operating temperature: -10 °C (min)

Min. operating temperature: -10 °C

Manufacturer part #: 3629

Material (details): Body: Zinc die-cast

Connection: M5

Max. operating pressure: 8 bar

Operating pressure (min.): -0.95 bar

Pressure range: -0.95 up to 8 bar

Operating medium: Compressed air

Pipe Ø: 2 mm

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2115111 FESTO Wheel lever valve R-3-M5 3629 -0.95 up to 8 bar External thread M5 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2115111 FESTO Wheel lever valve R-3-M5 3629 -0.95 up to 8 bar External thread M5 1 pc(s)

Information

Information 2115111 FESTO Wheel lever valve R-3-M5 3629 -0.95 up to 8 bar External thread M5 1 pc(s)

Description

Roller lever valve R-3-M5 valve function = 3/2 closed, mono-stable, operating method = mechanically, normal rated flow = 80 l/min, Operating pressure = -0,95 - 8 bar, constructive design = plate Seat

This text is machine translated.
