Name: Ground modular terminal block ST 4-QUATTRO/2P-PE 3042858 Phoenix Contact
Brand: Phoenix Contact
SKU: 565812
Availability: InStock

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

A multi-storey yellow-green terminal block for electrical wiring, with a side view of the metal connections and plastic housing.

Product type

PG terminal

Connection

Pull spring

Cross section (flexible) (max.)

4 mm²

Cross section (inflexible) (max.)

6 mm²

Content

50 pc(s)

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 30 Oct

8 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 50 pc(s))

Set(s)

Total (€ 6.70 / piece)

€ 335.00

incl. VAT

Only 8 Set(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Ground modular terminal block ST 4-QUATTRO/2P-PE

ST 4-QUATTRO/2P-PE

Technical specifications

Product type: PG terminal

Connection: Pull spring

Cross section (flexible) (min.): 0.08 mm²

Cross section (flexible) (max.): 4 mm²

Cross section (inflexible) (min.): 0.08 mm²

Cross section (inflexible) (max.): 6 mm²

AWG (min.): 28

AWG max.: 10

Clamp width: 6.2 mm

No. of rows: 1

Pins per row: 4

Number of pins: 4

Factory colour: Green
Yellow

Min. stripping length: 8 mm

Stripping length (max.): 10 mm

Manufacturer part #: 3042858

Content: 50 pc(s)

Industrial packaging: Yes

Type: ST 4-QUATTRO/2P-PE

Dim: (L x W x H) 97.3 x 6.2 x 36.5 mm

Width: 6.2 mm

Height: 36.5 mm

Length: 97.3 mm

Contamination level: 3

Flammability rating: V0

Insulation material: PA

Insulation: PA

UKCA: not relevant

Variants(All information include VAT, plus shipping costs)

Connection

Cross section (flexible) (max.)

Cross section (flexible) (min.)

Cross section (inflexible) (max.)

Cross section (inflexible) (min.)

Product type

Ground modular terminal block ST 4-QUATTRO/2P-PE 3042858 Phoenix Contact

Item no:565812

Dispatches on Fri 30 Oct

8 Set(s)Conrad Electronic

This article

Pull spring

4 mm²

0.08 mm²

6 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 335.00^*

Ground modular terminal block ST 2,5-QUATTRO/2P-PE 3040041 Phoenix Contact

Item no:565543

Dispatches on Fri 30 Oct

2 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 305.00^*

Ground modular terminal block ST 2,5-QUATTRO/4P-PE 3042162 Phoenix Contact

Item no:565751

Dispatches on Fri 30 Oct

4 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 295.00^*

Ground modular terminal block ST 2,5-TWIN/ 1P-PE 3042120 Phoenix Contact

Item no:565753

Dispatches on Fri 30 Oct

178 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 249.99^*

Ground modular terminal block ST 2,5/2P-PE 3042146 Phoenix Contact

Item no:565764

Dispatches on Fri 30 Oct

27 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 204.99^*

Ground modular terminal block ST 4/ 1P-PE 3042722 Phoenix Contact

Item no:565801

Dispatches on Fri 30 Oct

7 Set(s)Conrad Electronic

Pull spring

4 mm²

0.08 mm²

6 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 219.99^*

Protective conductor double-level terminal block PTTB 2,5/2P-PE 3210897 Phoenix Contact

Item no:566418

Dispatches on Fri 30 Oct

104 Set(s)Conrad Electronic

Quick-connect

2.5 mm²

0.14 mm²

4 mm²

0.14 mm²

Dual port PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 285.00^*

Protective conductor double-level terminal block STTB 2,5/2P-PE 3040067 Phoenix Contact

Item no:565547

Dispatches on Fri 30 Oct

82 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

Dual port PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 409.00^*

Protective conductor double-level terminal block STTB 2,5/2P-PE SO 3040915 Phoenix Contact

Item no:566307

Dispatches on Fri 30 Oct

1 Set(s)Conrad Electronic

Pull spring

2.5 mm²

0.08 mm²

4 mm²

0.08 mm²

Dual port PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 465.00^*

Ground modular terminal block ST 4/ 2P-PE 3042748 Phoenix Contact

Item no:565995

Unavailable

Conrad Electronic

Pull spring

4 mm²

0.08 mm²

6 mm²

0.08 mm²

PG terminal

Piece(s)

Minimum order quantity: 1

Multiple: 1

Documents & Downloads

Datasheet

Datasheet 565812 Ground modular terminal block ST 4-QUATTRO/2P-PE 3042858 Phoenix Contact

User & Safety Instructions

User & Safety Instructions 565812 Ground modular terminal block ST 4-QUATTRO/2P-PE 3042858 Phoenix Contact

Description

Ground modular terminal block, Connection method: Spring-cage/plug-in connection, Cross section: 0.08 mm² - 6 mm², AWG: 28 - 10, Width: 6.2 mm, Color: green-yellow, Mounting type: NS 35/7,5, NS 35/15
