HIKVISION DS-2CD2686G2H-IZS(2.8-12mm)(eF) 311331208
EAN:
Part number:
Item no:
Number
Total (€ 549.00 / piece)
€ 549.00
incl. VAT
14-day return policy included
Highlights & Details
HIKVISION 311331208 DS-2CD2686G2H-IZS(2.8-12mm)(eF)
- 1/1.8" Progressive Scan CMOS
- H.265+/H.265/H.264+/H.264/MJPEG
- Powered by Darkfighter technology, Color: 0,003 Lux @ (F1.4, AGC ON), 0 lux with IR
- 25fps/24fps(3840×2160), 25fps/30fps (3200x1800, 2688×1520, 1920×1080)
- VCA functions
- 3 streams
- 3D DNR
- BLC/HLC
- ICR
- ExIR, up to 60 m
- DC12V&PoE
- Micro SD/SDHC/SDXC slot
- HIK-Connect cloud service
- Audio/alarm I/O
- 2.8mm-12mm
- This text is machine translated.
Technical specifications
- Sensor
1/1.8" Progressive Scan CMOS
- Series
ABUS Professional
- Resolution
8 MP (maximum 3840 × 2160 pixels)
- Light sensitivity
Colour: 0.0008 Lux @ (F1.2, AGC ON), Black/White: 0 Lux with IR
- Operating voltage
12 VDC (± 25%) or PoE (IEEE 802.3at)
- Dim
(Ø x H) 140 mm x 144 mm
- Connections
1x RJ45 (10 M/100 M Ethernet)
Audio input and output via two-pin terminal block
1 Alarm input
1 alarm output and an integrated slot for microSD/microSDHC/microSDXC memory cards (up to 512 GB)
- No. of channels (details)
6
- Audio inputs
1 audio input (Line-In) as two-pin terminal block, maximum input amplitude 3.3 Vpp, input impedance 4.7 KΩ
- Resolution (max.)
3840 x 2160 p
- Outputs
1 audio output (line-out)
1 Alarm output (max. 24 VDC/24 VAC, 1 A)
- External dimensions
Ø 140 mm × 333,8 mm
- Outside Ø
140 mm
- Operating temperature
-30 °C to 60 °C
- Aperture
F1.2
- Inputs
1 Audio-input
1 Alarm input
- Used at
Outdoors
- Weight
1475 g
- Factory colour
Multicolour
- IR coverage
60 m
- Additional IR light
Yes
- Impedance
4.7 KΩ at the audio input and 100 Ω at the audio output
- Camera type
Bullet camera
- Height
144 mm
- Length
333.8 mm
- (Ø)
140 mm
IP67
- Visible screen size (diagonal)
137,4° bis 47,3°
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3742922 HIKVISION DS-2CD2686G2H-IZS(2.8-12mm)(eF) 311331208
Description
Features
- Bullet
- Motorized Lens
- IP66
- IK10
- 8MP
Scope of delivery
- Incl. drilling template
- Fitting Material
- Quick guide
Hints
Mains adapter not included
System requirements
- Windows, iOS, Android
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
