IMI NORGREN Pressure switch 0882200000000000 11 up to 17 bar 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 142.85 / piece)
€ 142.85
plus VAT.
14-day return policy included
Technical specifications
- Type
0882200000000000
- Product type
Pressure switch
- Min. switching pressure range
11 bar
- Max. switching pressure range
17 bar
- Switching pressure
11 up to 17 bar
- Operating temperature
-10 °C (min)
- Min. operating temperature
-10 °C
- Manufacturer part #
0882200000000000
- Dim
(L x W x H) 30 x 30 x 87.5 mm
- Width
30 mm
- Length
30 mm
- Height
87.5 mm
IP65
- Material
Aluminium
- Max. operating pressure
160 bar
- Operating pressure (min.)
10 bar
- Max. ambient temperature
+80 °C
- Min. ambient temperature
-10 °C
Documents & Downloads
Datasheet
Datasheet 3296490 IMI NORGREN Pressure switch 0882200000000000 11 up to 17 bar 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3296490 IMI NORGREN Pressure switch 0882200000000000 11 up to 17 bar 1 pc(s)
Description
18D Electromechanical pneumatic pressure switch
