MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 14.28
3
6% = € 0.79
€ 13.49
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 14.28 / piece)
€ 14.28
plus VAT.
14-day return policy included
Highlights & Details
AC/DC converter modules
- Output 12 V / 2500 mA
- Power 30 W
- Screw terminal
Technical specifications
- Type
switched-mode
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
2500 mA
- Output current (max.) - rounded
2.5 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 91 x 39.5 x 28.5 mm
- Output voltage (max.)
12 V
- Connection
Screw terminal
30 W
- No. of outputs
1 x
- Weight
120 g
- Type
Synchronised
- Width
39.5 mm
- Height
28.5 mm
- Length
91 mm
- Type
IRM-30-12ST
- No. of inputs
1 x
- Output voltage
15 V
- Output current (details)
2 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1371700 MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
User & Safety Instructions
User & Safety Instructions 1371700 MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
Information
Information 1371700 MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
Conformity certificate
Conformity certificate 1371700 MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
Warranty Terms
Warranty Terms 1371700 MEAN WELL IRM-30-12ST AC/DC PSU (print) 12 V 2500 mA 30 W
Description
AC/DC converter modules in case enclosure zur PCB mounting with an input voltage range of 85-264 V/AC. cooling by free air convection.
Features
- case
- IRM-30-_: PCB mounting
- universal input
- protections: short circuit and over load
- cooling by free air convection
- low no load power consumption
- insulation class II
