PENTATECH Motion detector FD25 White Set 82 dB 34112
EAN:
Part number:
Item no:
Number
Total (€ 41.17 / piece)
€ 41.17
plus VAT.
Only 10 Piece(s) available
Highlights & Details
Radio entry detector with Gong unit
- Motion detection
- Message to Gong unit through sound and/or flashing light
- Ideal for input range monitoring
Technical specifications
- Sensor:
- Location: Internal Area
- Operating voltage: 3 V DC
- Power consumption: 30 μA (idle), 15 mA (Operation)
- Power supply 2 x AAA battery or micro-USB power supply 5V DC, min. 100 mA
- Detection range: approx. 5 m, 98° (horizontal), approx. 9 m, 40° (vertical)
- Gong unit:
- Operating voltage 230 V AC, 50 Hz
- Power consumption: max. 0.1 W (Standby), max. 0.5 W (operation)
- Flashing light: 4 x LED
- Location: Internal Area
- Product type
Mini alarm system
- Component
Motion detector
- Power supply (LOV)
battery-powered
mains-powered
70 m
Doesn't apply
- Receiver size
85 x 54 x 35 mm
- Transmitter dimensions
87 x 80 x 28 mm
- Display
No
- Radio frequency
433.92 MHz
- Weight
146 g
- Factory colour
White
- Mounting type
Ceiling
Wall
Free standing
- Sound pressure
82 dB
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1589595 PENTATECH Motion detector FD25 White Set 82 dB 34112
Description
Warns for motion detection. Installation free and ready for immediate use.
Easy to attach. No matter, whether you want to set up or mounted on the wall or ceiling, an inexpensive entry detector is extremely effective. The motion detector's integrated PIR sensor reacts to movement and triggers at the gong unit a bright flashing light, siren or one of 24 selectable melodies.
Practical all-rounder.
The FD25 can be used for the monitoring of corridors, rooms and open doors, on the announcement of visitors or customers. No matter whether in the home, shop, office or hotel room - the continuity detector is ready for immediate use. The Gong unit is simply plugged into an outlet.
This text is machine translated.
Easy to attach. No matter, whether you want to set up or mounted on the wall or ceiling, an inexpensive entry detector is extremely effective. The motion detector's integrated PIR sensor reacts to movement and triggers at the gong unit a bright flashing light, siren or one of 24 selectable melodies.
Practical all-rounder.
The FD25 can be used for the monitoring of corridors, rooms and open doors, on the announcement of visitors or customers. No matter whether in the home, shop, office or hotel room - the continuity detector is ready for immediate use. The Gong unit is simply plugged into an outlet.
This text is machine translated.
Features
- Passive infrared motion detector with Fresnel lens
- Message via gongton or flashing light
- 4 volume can be set
- 24 melodies can be selected
- Optical warning only by blinkllicht possible
- Combination of several sets possible
Scope of delivery
- Gong unit
- Motion detector
- Fasteners
- User manual.
Hints
For operation, two AAA batteries required (not included). Please order separately (Order No. 652303).
Micro-USB power supply not included in the delivery.
