Name: Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)
Brand: Pfannenberg
SKU: 3779659
Availability: BackOrder

White electrical plug adapter with universal socket openings and side ventilation slats, shown in a product-style close-up.

Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)-1

Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)-2

Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)-3

Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)-4

1/5

Packaging type

Single

Product type

Thermostat

Connection

Screw terminal

Contact type

1 maker

Type

FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F

Datasheet (PDF)

Dispatches on Fri 23 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 46.99 / piece)

€ 46.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Mounting type: Clamp fixing

Packaging type: Single

Product type: Thermostat

Type: FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F

Connection: Screw terminal

Adjustment range (min.) (temperature): -20 °C

Temperature adjustment range (max.): 40 °C

Features: EMC

Contact type: 1 maker

Type: Thermostat

Test current: 10 A

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3779659 Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3779659 Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)

Conformity certificate

Conformity certificate 3779659 Pfannenberg Thermostat FLZ 530 THERMOSTAT -20..-40°C,-5..+105°F 1 maker Single 1 pc(s)

Description

Double temperature setting scale for Celsius and Fahrenheit.

Thermostats are used as temperature controllers and thus for control of filter fans or control cabinet heaters They are designed as NC/NO and change-over contacts. In combination with control cabinet heaters, they can ensure that the control cabinet is 'artificially' dehumidified in addition to temperature control, especially in outdoor applications. This means that the temperature is kept above the dew point so that no water falls out of the air and there may be short circuits due to condensation. The combination with filter fans offers additional energy, material and time savings and thus a better environmental balance and more safety in the production process through reduced energy consumption and improvement of the efficiency of the filter fans. The series of twin thermostats combines 2 thermostats in all combinations for complex switching tasks.

FLZ530 as a normally open contact with spring contact
- Suitable for controlling fans
- Switching temperature difference <7K
- Switching point tolerance +/-4K
- Setting range -20C to 40C or -5F to 105F (dual scale)

Thermostats for every application
- FLZ510: Toggle switch with spring contact
- FLZ520: NC contact with quick-action contact (suitable for controlling heating systems)
- FLZ530: NO contact with spring contact (suitable for controlling fans)
- FLZ541: NC and NO contact with spring contact in a housing
- FLZ542: Two NC contacts with spring contact in one housing
- FLZ543: Two NO contacts with spring contact in one housing

The advantages of this series at a glance
- Suitable for all applications in industry
- No interference from EM radiation because a mechanically switching contact is installed
- Extends the operating time of heaters and fans
- Optimized energy consumption for heating and filter fans
- Easy mounting on DIN rails
- Electrical connection via screw terminals
- IP 20 protection for mounting inside the control cabinet
- Approvals: CURus, EAC, CSA
