Buy Phoenix Contact 1713037 Screw terminal 2.50 mm² Number of pins 3 Green 100 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Green connector with five inputs and metal pins, typical for electronic printed circuit board connections.

Green connector with five inputs and metal pins, typical for electronic printed circuit board connections.

Image similar

Phoenix Contact

Product type

Screw terminal

CS

5.00 mm

Pins per row

3

Number of pins

3

Connection

Screw terminal

Print

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

97 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 100 pc(s))

Set(s)

Total (€ 1.45 / piece)

€ 144.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block SMKDS 3/ 3

Content 100 pc(s)

Technical specifications

Type: SMKDS 3/ 3

Product type: Screw terminal

Features: + extractor sleeve

CS: 5.00 mm

Pins per row: 3

Number of pins: 3

Series: SMKDS

Stripping length (max.): 8.00 mm

Connection: Screw terminal
Print

Nominal current: 24 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 24 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (max.): 4.00 mm²

AWG (min.): 24

Connector orientation: At an angle (to the PCB)

AWG max.: 12

Contact material: Tin plated

Factory colour: Green

Actuation direction: At an angle (to the PCB)

Manufacturer part #: 1713037

Industrial packaging: Yes

Content: 100 pc(s)

Nominal voltage: 400 V

Height: 18.00 mm

Length: 16.00 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 788035 Phoenix Contact 1713037 Screw terminal 2.50 mm² Number of pins 3 Green 100 pc(s)

User & Safety Instructions

User & Safety Instructions 788035 Phoenix Contact 1713037 Screw terminal 2.50 mm² Number of pins 3 Green 100 pc(s)

Description

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 35 °, Color: green, The article can be aligned to create different nos. of positions!

Description

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 35 °, Color: green, The article can be aligned to create different nos. of positions!
