Image similar
Phoenix Contact 1988804 Screw terminal 2.50 mm² Number of pins 2 Green 250 pc(s)
Product type
Screw terminal
CS
5.00 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 250 pc(s))
Total (€ 0.54 / piece)
€ 134.99
incl. VAT
14-day return policy included
Highlights & Details
Screw compact terminal block PTA 1,5/ 2-5,0
- PTA 1.5/ 2-5.0
- Industrial packaging with 250 pieces
Technical specifications
- Type
PTA 1,5/ 2-5,0
- Product type
Screw terminal
- CS
5.00 mm
- Pins per row
2
- Number of pins
2
- Series
PTA
- Stripping length (max.)
5.00 mm
- Connection
Screw terminal
Print
- Nominal current
17.5 A
- Cross section (flexible) (min.)
0.14 mm²
- Nominal current - rounded value
17.5 A
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
2.50 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
26
- Connector orientation
At an angle (to the PCB)
- AWG max.
14
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
At an angle (to the PCB)
- Manufacturer part #
1988804
- Industrial packaging
Yes
- Content
250 pc(s)
- Nominal voltage
400 V
- Width
15.40 mm
- Height
12.80 mm
- Length
10.00 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 569799 Phoenix Contact 1988804 Screw terminal 2.50 mm² Number of pins 2 Green 250 pc(s)
User & Safety Instructions
User & Safety Instructions 569799 Phoenix Contact 1988804 Screw terminal 2.50 mm² Number of pins 2 Green 250 pc(s)
Description
PCB terminal block, Nominal current: 17.5 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 45 °, Color: green
