REED Electronics R1/8"-EO/S-L45-E27Z-1mPVC Float switch 230 V AC 0.4 A 1 maker, 1 breaker IP67 1 pc(s)
EAN:
Part number:
Item no:
Product type
Float switch
Contact type
1 maker
1 breaker
Material
Stainless steel
Switching voltage
230 V AC
Switching current (max.)
0.4 A
Datasheet (PDF)
Number
Total (€ 54.22 / piece)
€ 54.22
plus VAT.
Highlights & Details
REED Electronics R1/8"-EO/S-L45-E27Z-1mPVC Float switch 230 V AC 0.4 A 1 maker, 1 breaker IP67 1 pc(s)
Our service for you
Technical specifications
- Product type
Float switch
- Contact type
1 maker
1 breaker
- Material
Stainless steel
- Connection
Open end cable
- Cable length
1.00 m
- Switching voltage
230 V AC
- Switching current (max.)
0.4 A
10 W
- Min. temperature
-5 °C
- Max. temperature
+80 °C
- (Ø)
27 mm
- Thread size
G1/8"
- Recess diameter
8.8 mm
IP67
- Dim
(Ø) 27 mm
- RoHS-compliant
Yes
- Type
R1/8"-EO/S-L45-E27Z-1mPVC
- Material (details)
V4A
- Type
R1/8"-EO/S-L45-E27Z-1mPVC
