Image similar
Image similar
Relay Module PLC-RSC-230UC/ 2AU/SEN 2966443 Phoenix Contact
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 10 pc(s))
Total (€ 201.67 / piece)
€
Highlights & Details
Relay Module PLC-RSC-230UC/ 2AU/SEN
- Industrial packaging, pack of 10
Technical specifications
- Type
PLC-RSC-230UC/ 2AU/SEN
- Connection
Screw terminal
- Contact type
1 breaker
- Contact material
Ag-hard gold plated
- Nominal voltage
220 V DC
230 V AC
- Switching voltage (max.)
36 V DC
30 V AC
- Switching current (max.)
50 mA
- Features
+ LED
+ diode bridge
IP20
- Max. temperature
+55 °C
- Min. temperature
-25 °C
- Depth
94 mm
- Width
6.2 mm
- Height
80 mm
- Dim
(W x H x D) 6.2 x 80 x 94 mm
- Content
10 pc(s)
- Industrial packaging
Yes
- RoHS-compliant
- Product type
Interface relay
Documents & Downloads
Datasheet
Datasheet 705590 Relay Module PLC-RSC-230UC/ 2AU/SEN 2966443 Phoenix Contact
User & Safety Instructions
User & Safety Instructions 705590 Relay Module PLC-RSC-230UC/ 2AU/SEN 2966443 Phoenix Contact
Description
PLC sensor relay, consisting of basic terminal block PLC-BSC...SEN with screw connection and pluggable miniature relay with multi-layer contact, for assembly on DIN rail NS 35/7.5, 1 N/C contact, input voltage 230 V AC/220 V DC
