Schneider Electric METSEEM3712 METSEEM3712 Energy logger Digital 5 A 1 pc(s)

The PowerLogic EM3000 series includes a series of three-phase, DIN-rail mounted energy counters with backlit LCD display. Measurement of active energy and effective power. The supply voltage can be between 100 and 277 VAC in 50 Hz or 60 Hz networks, or between 173 and 480 VAC. The rated current flows through a current transformer with 1 A or 5 A, which is measured in this measuring instrument. With an x / 1A current transformer, the meter offers the following accuracy, effective energy class 1 according to IEC62053-21 and IEC61557-12. Thanks to an x/5A current transformer, accuracy is improved to Class 0.5 S according to IEC62053-22 and IEC61557-12 at the same active energy. Communication is ensured by a digital pulse output for power measurement. This meter can be used for partial billing and partial counting applications. Product dimensions are as follows: Width 90 mm, depth 69 mm, height 95 mm and product weight 255 g. Additional local signaling includes a green LED indicator, flashing yellow LED for accuracy testing and communication indicators. Certifications include CE and UL. The meter can be installed in single-phase and neutral (1P+N), three-phase (3P) and three-phase neutral (3P+N) networks.

This text is machine translated.
