Counttec BTK30 DZ1004Q Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electricity meter (3-phase)
Display
Digital
Operating voltage
3 x 230/400 V
Dim
(L x W x H) 88.5 x 155 x 216 mm
Weight
910 g
Datasheet (PDF)
Number
Total (€ 88.23 / piece)
€ 88.23
plus VAT.
Only 1 Piece(s) available
Highlights & Details
Dual direction three-phase meter for mounting in cross counter (A+/A-)
- Warnings from various events are shown on the LC display
- This text is machine translated.
Technical specifications
- Counter type: 3-phase, 4-conductor, active & reactive, import & exportMeasuring method: Direct measurementAccuracy class Active: Class C (EN 50470-1/3)Accuracy class reactive: Class 2 (EN 62053-23)Rated voltage (Un): 3x230/400 VOperating voltage range 0.8 Un ~ 1.15 UnReference frequency 50 Hz ±5 %Start-up current (Ist) 20 mAMinimum current (Imin): 0.15 A.Contact current (ITR) 0.5 A.Nominal current (In) 5 AMaximum current (Imax): 100 A.IP protection: T IP54 (outside)Protection class II (two)OPERATING TEMPERATURE -40 °C ~ +70 °C (3K7)Mechanical environment class M1 (according to 2014/32/EU)Electromagnetic environment: Class E2 (according to 2014/32/EU)Power consumption of the voltage circuit < 1 W, 2 VAPower consumption of the circuit: < 1 VAESD strength (electrostatic discharge): Contact: 8 kV; air: 15 kVSurge voltage resistance: 6 kVMeter constant: 1000 Imp/kWh 1000 imp/varh Ind. 1000 IMP/kVarh cap.LCD display: 6+3 and additional characters with backlightCommunication: N Optical (IR) and RS485 300-19200 Baud (EN 62056-21)Real-time clock accuracy < : 0.5 sec/day (EN 62054-21)
- Product type
Electricity meter (3-phase)
- Display
Digital
- Operating voltage
3 x 230/400 V
- Dim
(L x W x H) 88.5 x 155 x 216 mm
- Weight
910 g
- Starting current
20 mA
- Starting current
20 mA
- Operating voltage
230 V
400 V
- Accuracy class
Class C (EN 50470-1/3)Class 2 (EN 62053-23)
- MID-approved
Yes
- Reading type
Energy consumption
- Width
155 mm
- Height
216 mm
- Length
88.5 mm
- Current (max.)
100 A
- Current (min.)
0.15 A
- Current range
0.15 up to 100 A
- Type
BTK30
- Effective current range
0.15 A ~ 100 A A
Documents & Downloads
Datasheet
Datasheet 2686586 Counttec BTK30 DZ1004Q Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
Datasheet 2686586 Counttec BTK30 DZ1004Q Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2686586 Counttec BTK30 DZ1004Q Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
Information
Information 2686586 Counttec BTK30 DZ1004Q Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
Description
Scope of delivery
- Including terminal cover
