SIKU 27528 In-line extractor 230 V 185 m³/h 12.5 cm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 37.99 / piece)
€ 37.99
incl. VAT
Only 10 Piece(s) available
Highlights & Details
Pipe-rack fan KL 125
- Ball bearing motor
Technical specifications
- Product type
In-line extractor
- Nominal voltage
230 V
- Current consumption
100 mA
16 W
- Air flow rate
185 m³/h
- Rotational speed
2400 U/min
- Suitable for pipe Ø
12.5 cm
- Noise emission (max.)
38 dB
IPX4
- Factory colour
White
- Max. noise generation
38 dBa
- Max. power consumption
16 W
- Output
185 m³/h
- Operating voltage
230 V/50 Hz
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 560211 SIKU 27528 In-line extractor 230 V 185 m³/h 12.5 cm
User & Safety Instructions
User & Safety Instructions 560211 SIKU 27528 In-line extractor 230 V 185 m³/h 12.5 cm
Warranty Terms
Warranty Terms 560211 SIKU 27528 In-line extractor 230 V 185 m³/h 12.5 cm
Description
Pipe-rack fan with ball bearing motor for installation in ventilation systems. Suitable for Exhaust pipes and hoses in Ø 125 mm. Made out of high-quality ABS plastic.
Scope of delivery
- Tube Fan Inserts
- User manual.
