Sol Expert 90444 CarSystem lighting kit 1 - 3 V (L x W x H) 14 x 6 x 3.5 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 7.55
3
5% = € 0.41
€ 7.14
5
8% = € 0.58
€ 6.97
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 7.55 / piece)
€ 7.55
plus VAT.
Highlights & Details
Car Lighting System
- Model Car Tuning
Technical specifications
- Size
H0
- Voltage (min.)
1 V
- Voltage (max.)
3 V
- Length
14 mm
- Width
6 mm
- Height
3.5 mm
- Dim
(L x W x H) 14 x 6 x 3.5 mm
- Age category
15 years and over
- Product type
CarSystem lighting kit
Documents & Downloads
Datasheet
Datasheet 1377842 Sol Expert 90444 CarSystem lighting kit 1 - 3 V (L x W x H) 14 x 6 x 3.5 mm
User & Safety Instructions
User & Safety Instructions 1377842 Sol Expert 90444 CarSystem lighting kit 1 - 3 V (L x W x H) 14 x 6 x 3.5 mm
Description
In order to be able to operate white LEDs in wired vehicles despite only two NiMH batteries, this small circuit makes sense.
With it the complete vehicle lighting can be realized by means of white and red LED. No further series resistors are required.
Alternatively, the circuit can be supplied with one (1.2 V) or two (2.4 V) NiMH rechargeable batteries. The LEDs are connected in parallel to the corresponding outputs for red or white LEDs. Of course, other colors can also be used here.
This text is machine translated.
With it the complete vehicle lighting can be realized by means of white and red LED. No further series resistors are required.
Alternatively, the circuit can be supplied with one (1.2 V) or two (2.4 V) NiMH rechargeable batteries. The LEDs are connected in parallel to the corresponding outputs for red or white LEDs. Of course, other colors can also be used here.
This text is machine translated.
Scope of delivery
- 1 lighting board
- 2 LEDs red
- 2 LEDs warm-white.
