1/3
TE Connectivity Sensor EVS722-51 Float switch 250 V AC, 100 V DC 1 A 1 maker, 1 breaker IP65 1 pc(s)
Product type
Float switch
Contact type
1 maker
1 breaker
Material
Polyamide 6.6
Switching voltage
250 V AC
100 V DC
Switching current (max.)
1 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 83.96 / piece)
€ 83.96
incl. VAT
14-day return policy included
Technical specifications
- Installation depth: 220 mm
- Product type
Float switch
- Contact type
1 maker
1 breaker
- Material
Polyamide 6.6
- Connection
Open end cable
- Cable length
0.50 m
- Switching voltage
250 V AC
100 V DC
- Switching current (max.)
1 A
15 W
- Min. temperature
-30 °C
- Max. temperature
+110 °C
- Thread size
M16
IP65
- Type
EVS722-51
- Type
Brass housing with PP float
- Thread size
M16
- Switching capacity
15 W
- Temperature range
-30 - +110 °C
Documents & Downloads
Datasheet
Datasheet 155133 TE Connectivity Sensor EVS722-51 Float switch 250 V AC, 100 V DC 1 A 1 maker, 1 breaker IP65 1 pc(s)
User & Safety Instructions
User & Safety Instructions 155133 TE Connectivity Sensor EVS722-51 Float switch 250 V AC, 100 V DC 1 A 1 maker, 1 breaker IP65 1 pc(s)
Description
Resistant to weak inorganic acids and alkalis, alcohol, oils and washing sodas up to 100 ºC.
Scope of delivery
- Supplied with fittings and seals for internal and external mounting
