TP-LINK VIGI NVR1004H-4P VIGI NVR1004H-4P IP Network video recorder 3840 x 2160 p
EAN:
Part number:
Item no:
Number
Total (€ 117.64 / piece)
€ 117.64
plus VAT.
Only 2 Piece(s) available
IP-3840 x 2160 p;TP-LINKVIGI NVR1004H-4P;VIGI NVR1004H-4PIndoors
Highlights & Details
- Video input channels: 4 channels
- 3840 x 2160 pixels
- Input bandwidth: 80 Mbps Output bandwidth: 60 Mbps
- Max. Storage capacity 10 TB HDD
- Interface SATA
- Number of Ethernet LAN connections (RJ-45): 1
Technical specifications
- Video input channels: 4 channels
- 80 Mbps input bandwidth
- Output bandwidth 60 Mbit/s.
- Product type
Network video recorder
- Resolution (max.)
3840 x 2160 p
- Used at
Indoors
- Width
246.2 mm
- Height
45 mm
- Depth
148.2 mm
- Dim
(W x H x D) 246.2 x 45 x 148.2 mm
- Factory colour
Black
- Signal standard
IP
- Display resolution
3840 x 2160 Pixel
- No. of HDMI ports
1 x
- No. of USB A 2.0 ports
2 x
- Keyboard layout
German, QWERTZ
- Memory capacity
0 GB
- Max. output current
1.31 A
- Output voltage
53.5 V
- 10/100/1000 Mbps ports
1 x
- Power consumption (ON)
4.25 W
- Wi-Fi
No
- UKCA
yes
- Operating temperature (T-T)
-10 - 55 °C
- Total Power over Ethernet (PoE) budget
53 W
- Audio RCA inputs
1
- Audio RCA outputs
1
- HDMI output
yes
- Alarm input channels
4
- Alarm output channels
1
- Maximum storage capacity
10 TB
- VGA (D-Sub) output ports
1
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3808171 TP-LINK VIGI NVR1004H-4P VIGI NVR1004H-4P IP Network video recorder 3840 x 2160 p
Information
Information 3808171 TP-LINK VIGI NVR1004H-4P VIGI NVR1004H-4P IP Network video recorder 3840 x 2160 p
Conformity certificate
Conformity certificate 3808171 TP-LINK VIGI NVR1004H-4P VIGI NVR1004H-4P IP Network video recorder 3840 x 2160 p
Description
Compact 4-channel network video recorder with integrated 4-port PoE+ switch (802.3af/at) for direct power supply and data transfer from IP cameras via a single Ethernet cable. The recorder supports up to 4 channels of decoding at 2 megapixels (or 1 channel at 8 megapixels) and works with highly efficient H.265+ video compression to minimize bandwidth and memory. Equipped with a SATA connection for hard disks up to 10 TB allows the device to continuously record 24/7. The seamless integration into the VIGI ecosystem allows quick start-up via plug-and-play as well as flexible remote access via the VIGI APP or the web client.
This text is machine translated.
This text is machine translated.
Features
- Integrated 4-port PoE+ switch (802.3af/at)
- Automatic IP camera detection (Plug & Play)
- 24/7-continuous recording
- Highly efficient H.265+ video compression
- Remote access via VIGI APP and web client; ONVIF compatibility
Scope of delivery
- Inclusive of power supply with power cable
- USB mouse
- 19" rack holder
- Screw
- Rubber buffer for housing
- User manual.
- HDD-cable
- CCTV sign
Hints
Hard disk not included
System requirements
- Windows, iOS, Android
