TracoPower THN 20-2410WIR DC/DC converter 3.3 V DC 5.5 A 20 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 65.99 / piece)
€ 65.99
incl. VAT
14-day return policy included
Highlights & Details
DC DC Converters
- Output 3.3 V DC / 5.5 A
- Power 20 W
- Solder pins
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36.0 V DC
- Max. output current
5.5 A
- Output current (max.) - rounded
5.5 A
- Min. input voltage
9.0 V DC
- Dim
(L x W x H) 25.4 x 25.4 x 15.5 mm
- Output voltage (max.)
3.3 V DC
- Connection
Solder pins
20 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
65 °C
- Operating temperature (min.)
-40 °C
- Weight
16 g
- Width
25.4 mm
- Height
15.5 mm
- Length
25.4 mm
- Type
THN 20-2410WIR
