TracoPower THN 20-2413WIR DC/DC converter 15 V DC 1.33 A 20 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 50.41 / piece)
€ 504.10
plus VAT.
Highlights & Details
DC DC Converters
- Output 15 V DC / 1.33 A
- Power 20 W
- Solder pins
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36.0 V DC
- Max. output current
1.33 A
- Output current (max.) - rounded
1.33 A
- Min. input voltage
9.0 V DC
- Dim
(L x W x H) 25.4 x 25.4 x 15.5 mm
- Output voltage (max.)
15 V DC
- Connection
Solder pins
20 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
65 °C
- Operating temperature (min.)
-40 °C
- Weight
16 g
- Width
25.4 mm
- Height
15.5 mm
- Length
25.4 mm
- Type
THN 20-2413WIR
