Visaton DK 8 - 100 V/20 Ohm Horn loudspeaker 30 W Silver 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 119.99 / piece)
€ 119.99
incl. VAT
14-day return policy included
Highlights & Details
Visaton DK8, 100 V/20 Ohm speakers
- An additional 20-Ohm-Einstellung possible
Our service for you
Technical specifications
- Product type
Horn loudspeaker
- RMS capacity
15 W
- Max. load
30 W
- Impedance
20 Ω
- Features
weatherproof
IP66
- Frequency range
500 - 5500 Hz
- Operating voltage
100 V
- Factory colour
Silver
- Material
Plastic
- Width
23.1 mm
- Height
12.7 mm
- Length
26.9 mm
- (Ø)
21 mm
- Weight
1.4
- Dim
(Ø x H) 21 mm x 12.7 mm
- Max. sound pressure
122 dB
Documents & Downloads
Datasheet
Datasheet 311695 Visaton DK 8 - 100 V/20 Ohm Horn loudspeaker 30 W Silver 1 pc(s)
User & Safety Instructions
User & Safety Instructions 311695 Visaton DK 8 - 100 V/20 Ohm Horn loudspeaker 30 W Silver 1 pc(s)
Description
Pressure chamber loudspeaker with 100 V transformer.
