Name: VOLTCRAFT VC-595OLED Clamp meter Digital OLED display CAT III 600 V, CAT II 1000 V Display (counts): 6000
Brand: VOLTCRAFT
SKU: 1230139
Availability: SoldOut

Highlights & Details

Digital clamp-on ammeter multimeter VC-595 OLED

CAT II 1000 V, CAT III 600 V
True RMS
Self-luminous OLED display
AC/DC current measurement up to 600 A
Non-contact voltage tester
Switchable measuring point lighting
Opening range of current clamps 30 mm

Our service for you

Technical specifications

NCV: 100 - 750 V/AC 50 - 60 Hz

Voltage reading range DC (min.): 0.001 V

Product type: Clamp meter

Voltage DC reading range (max.): 1000 V

V AC reading range (min.): 1 mV

V AC reading range (max.): 750 V

Amperage reading range DC (min.): 0.01 A

A DC reading range (max.): 600 A

A AC reading range (min.): 0.01 A

Amperage reading range AC (max.): 600 A

Reading range - resistance: 0.1 Ω - 60 MΩ

Reading range - capacity: 0.01 nF - 6 mF

DC resistance: 10 MΩ

AC resistance: 10 MΩ

Basic accuracy: 0.8 %

Measurement type (details): True RMS

Frequency range: 45 - 400 Hz

Power supply (details): 3x AAA battery

Height: 228 mm

Width: 77 mm

Weight: 265 g

: Manufacturer's standards (no certificate)

Reading category: CAT III 600 V
CAT II 1000 V

Voltage metering: AC/DC

Current reading: AC/DC

Type: VC-595OLED

Display: Digital

Display (counts): 6000

Dim: (W x H) 77 mm x 228 mm

Temperature reading range (max.): +1000 °C

Temperature reading range (min.): -40 °C

Features: OLED display

Opening range of current clamps: 30 mm

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1230139 VOLTCRAFT VC-595OLED Clamp meter Digital OLED display CAT III 600 V, CAT II 1000 V Display (counts): 6000

Radio certificate

Radio certificate 1230139 VOLTCRAFT VC-595OLED Clamp meter Digital OLED display CAT III 600 V, CAT II 1000 V Display (counts): 6000

Warranty Terms

Warranty Terms 1230139 VOLTCRAFT VC-595OLED Clamp meter Digital OLED display CAT III 600 V, CAT II 1000 V Display (counts): 6000

Description

Compact clamp meter with multimeter measurement functions for a safe measurement of alternating current up to 600 A. The ergonomic housing allows one-hand operation and is very robust by the molded soft rubber protection. The clamp-on ammeter multimeter combines standard multimeter functions with the comfortable advantage of contact-free power measurement. With the clamp multimeter eliminates the annoying separating the circuit for current measurement.

Factory calibration ensures accurate readings
Calibration according to manufacturer standards is part of Voltcraft Quality Assurance. This ensures high quality products and compliance with tolerance limits as outlined in the user manual. This does not include certification.

This text is machine translated.

Features

Data Hold
Auto-Power Off
Reads voltage, frequency, temperature, capacity and resistance
Diode and acoustic continuity tester
Non-contact voltage testing (NCV)
DC-ZERO function.

Scope of delivery

Batteries
Safety test leads
K-type thermocouple (-40 to +250 °C)
User manual.

Description

Compact clamp meter with multimeter measurement functions for a safe measurement of alternating current up to 600 A. The ergonomic housing allows one-hand operation and is very robust by the molded soft rubber protection. The clamp-on ammeter multimeter combines standard multimeter functions with the comfortable advantage of contact-free power measurement. With the clamp multimeter eliminates the annoying separating the circuit for current measurement.

Factory calibration ensures accurate readings
Calibration according to manufacturer standards is part of Voltcraft Quality Assurance. This ensures high quality products and compliance with tolerance limits as outlined in the user manual. This does not include certification.

This text is machine translated.
