WAGO 2000-5317/101-000 Actuator terminal 7 mm Pull spring Grey 50 pc(s) Package

A grey, multi-stage terminal block with multiple metal connections and coloured elements in the top left, used for wiring electrical circuits.
Circuit diagram: Two switches 'S1' and 'S2' connected, underneath a red one with '+' and a yellow-green PE earth terminal.
1/2
Image similar
Packaging type
Package
Product type
Actuator terminal
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Wed 18 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 11.50 / piece)
€ 575.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

3-Leiter-Aktrorenklemme 2000-5317/101-000

  • 2000-5317/101-000

Technical specifications

  • For NPN (minus) switching actuators
Packaging type

Package

Product type

Actuator terminal

Features

+ PG connector

Connection

Pull spring

Cross section (flexible) (min.)

0.14 mm²

Cross section (flexible) (max.)

1.50 mm²

Cross section (inflexible) (min.)

0.14 mm²

Cross section (inflexible) (max.)

1.50 mm²

AWG (min.)

24

AWG max.

16

Clamp width

7 mm

No. of rows

3

Pins per row

2

Number of pins

8

Factory colour

Grey

Nominal current

13.5 A

Nominal current - rounded value

13.5 A

Nominal voltage

250 V AC

Min. stripping length

9 mm

Stripping length (max.)

11 mm

Manufacturer part #

2000-5317/101-000

Content

50 pc(s)

Industrial packaging

Yes

Type

2000-5317/101-000

Connector colour

Grey

UKCA

not relevant
