WAGO 279-837 PG terminal 4 mm Pull spring Configuration: Terre Green, Yellow 100 pc(s) Package

Green-yellow electrical terminal block with metal contacts and lever mechanism, for secure fastening of cables in electrical installations.
Pictured is a green-yellow insulated electrical terminal block with the dimensions: height 27 mm, width 73 mm, depth 42.5 mm.
1/2
Packaging type
Package
Product type
PG terminal
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 20 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 100 pc(s))
Total (€ 5.75 / piece)
€ 575.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

4-conductor ground terminal block

  • 279-837
  • Industrial packaging with 100 pieces

Technical specifications

  • 4 COND. EARTH TERMINAL
Packaging type

Package

Product type

PG terminal

Features

spring-loaded

Connection

Pull spring

Configuration

Terre

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

1.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

1.50 mm²

AWG (min.)

28

AWG max.

16

Clamp width

4 mm

No. of rows

1

Pins per row

4

Number of pins

4

Factory colour

Green

Yellow

Nominal current

18 A

Nominal current - rounded value

18 A

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

279-837

Content

100 pc(s)

Industrial packaging

Yes

Type

279-837

Dim

(W x H) 4 mm x 27 mm

Width

4 mm

Height

27 mm

DIN rail (top hat rail) 35 mm

Green/yellow

4

73 mm

27 mm

105-105 °C

V0

TRUE

Spring clamp connection

Spring clamp connection

1

4

0.08-1.5 mm²

0.08-1.5 mm²

0.08-1.5 mm²

Thermoplastic

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 535422 WAGO 279-837 PG terminal 4 mm Pull spring Configuration: Terre Green, Yellow 100 pc(s) Package

User & Safety Instructions

User & Safety Instructions 535422 WAGO 279-837 PG terminal 4 mm Pull spring Configuration: Terre Green, Yellow 100 pc(s) Package

Description

Green-yellow.
