WAGO 280-560 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Piece

A grey two-storey terminal block with blue and yellow connection terminals for electrical wiring.
A grey, triangular electrical terminal block with three connection points and side couplings. Dimensions: 80 mm wide, 55.5 mm high.
Diagram shows two electrical conductor symbols at the top, one with '+' and brown box, another with '-' and blue box; third line connects two 'S' symbols.
1/3
Packaging type
Piece
Product type
Proximity switch terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Mon 16 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 4.60 / piece)
€ 229.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Sensor terminal block

  • 280-560
  • Industrial packaging, pack of 50

Technical specifications

  • SENSOR TERM.BL.W/O LED 380 V
Packaging type

Piece

Product type

Proximity switch terminal

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

5 mm

No. of rows

3

Number of pins

4

Factory colour

Grey

Nominal current

20 A

Nominal current - rounded value

20 A

Nominal voltage

400 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-560

Content

50 pc(s)

Industrial packaging

Yes

Type

280-560

Dim

(W x H) 5 mm x 55.50 mm

Width

5 mm

Height

55.50 mm

Contamination level

3

Connector colour

Grey

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 535838 WAGO 280-560 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 535838 WAGO 280-560 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Piece

Description

Grey.

This text is machine translated.
