WAGO 280-584 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 10 pc(s) Package

Three-storey grey clamp with blue and brown marking, side view. Used for electrical connections in control cabinets.
The circuit diagram shows two sliding controls: The upper control is labelled with '+' and a brown box, the lower with '-' and a blue box.
Grey electrical terminal block with dimensions: 90.5 mm width and 63.5 mm height. Two connections at the top, wire guides on the left/right.
1/3
Packaging type
Package
Product type
Proximity switch terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 20 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 10 pc(s))
Total (€ 3.60 / piece)
€ 35.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Sensor supply terminal block

  • 280-584
  • Industrial packaging, pack of 10

Technical specifications

  • SENS.SUPPLY T.BL.4COND.W/O LED 380V
Packaging type

Package

Product type

Proximity switch terminal

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

5 mm

No. of rows

2

Number of pins

2

Factory colour

Grey

Nominal current

20 A

Nominal current - rounded value

20 A

Nominal voltage

400 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-584

Content

10 pc(s)

Industrial packaging

Yes

Type

280-584

Dim

(L x W x H) 5 x 5 x 63.50 mm

Width

5 mm

Height

63.50 mm

Length

5 mm

Contamination level

3

Connector colour

Grey

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 535930 WAGO 280-584 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 10 pc(s) Package

User & Safety Instructions

User & Safety Instructions 535930 WAGO 280-584 Proximity switch terminal 5 mm Pull spring Configuration: L Grey 10 pc(s) Package

Description

Feed on the initiator side, without cover plate for 4-wire initiators, gray.
