Name: WAGO 727-119 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s)
Brand: WAGO
SKU: 542360
Availability: BackOrder

A theatre stage model with tiered seating rows; demonstrates the layout and arrangement of seats in an auditorium space.

Cross-section of an electronic assembly, comprising multiple circuit boards in a trapezoidal arrangement. Dimensions: 226 mm width, 58.5 mm height.

1/2

Product type

Shunt terminal

Connection

Pull spring

Cross section (flexible) (max.)

1.50 mm²

Cross section (inflexible) (max.)

1.50 mm²

Nominal current - rounded value

10 A

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Wed 18 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 25 pc(s))

Set(s)

Total (€ 21.40 / piece)

€ 535.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

8-level terminal block for matrix patching

727-119
Industrial packaging, pack of 25

Technical specifications

8-LEV.T.BL.F.MATRIX PAT.GREY 35X7.5

Product type: Shunt terminal

Features: + snap hook

Connection: Pull spring

Configuration: L

Cross section (flexible) (min.): 0.08 mm²

Cross section (flexible) (max.): 1.50 mm²

Cross section (inflexible) (min.): 0.08 mm²

Cross section (inflexible) (max.): 1.50 mm²

AWG (min.): 28

AWG max.: 16

Clamp width: 7.62 mm

No. of rows: 8

Pins per row: 4

Number of pins: 32

Factory colour: Grey

Nominal current: 10 A

Nominal current - rounded value: 10 A

Nominal voltage: 250 V

Min. stripping length: 8 mm

Stripping length (max.): 10 mm

Manufacturer part #: 727-119

Content: 25 pc(s)

Industrial packaging: Yes

Type: 727-119

Dim: (L x W x H) 7.62 x 7.62 x 76 mm

Width: 7.62 mm

Height: 76 mm

Length: 7.62 mm

Contamination level: 3

Connector colour: Grey

UKCA: not relevant

Variants(All information include VAT, plus shipping costs)

Factory colour

WAGO 727-119 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s)

Item no:542360

Dispatches on Wed 18 Nov

Conrad Electronic

This article

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 535.00^*

WAGO 727-119/001-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542368

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 559.00^*

WAGO 727-119/002-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542370

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 559.00^*

WAGO 727-119/003-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Piece

Item no:542371

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 559.00^*

WAGO 727-119/004-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542375

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 559.00^*

WAGO 727-120 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542382

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 529.00^*

WAGO 727-120/001-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542383

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 555.00^*

WAGO 727-120/002-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542384

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 555.00^*

WAGO 727-120/003-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542386

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 555.00^*

WAGO 727-120/004-000 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:542387

Dispatches on Wed 18 Nov

Conrad Electronic

Grey

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 555.00^*

Documents & Downloads

Datasheet

Datasheet 542360 WAGO 727-119 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s)

User & Safety Instructions

User & Safety Instructions 542360 WAGO 727-119 Shunt terminal 7.62 mm Pull spring Configuration: L Grey 25 pc(s)

Description

+ snap hook, not printed 8 x in pairs connect the clamping points which lie at the same level, according to EN 60715, gray.

This text is machine translated.

Description

+ snap hook, not printed 8 x in pairs connect the clamping points which lie at the same level, according to EN 60715, gray.

This text is machine translated.
