Buy Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

'Lila Lithium-ion battery 18650 with inscription "LI-ION 3500" and "GERMAN QUALITY CHECK", black positive terminal at the top, white background.'

Li-Ion Battery Pack with 'ANSBACH' Battery, Type 18650, 3.6 V, 3500 mAh. On the packaging it states '2 Years Warranty' and 'up to 2000 Charge Cycles'.

White battery cell with a purple cap, showing the inscription 'Protected' and 'Type-3500', 3250 mAh, 3.6V.

1/4

Datasheet (PDF)

Fast track dispatch on Wed, 9 Sep

209 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 18.48 / piece)

€ 18.48

plus VAT.

Report legal concerns

Li-ion battery 18650

Highlights & Details

Li-ion 18650 battery 3.6V 3500mAh (12.6Wh)
4-way safety thanks to protective electronics
Temperature resistant from 0°C up to 60°C

Technical specifications

Charging according to the CC-CV-characteristic curve

Size: 18650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 18.5 mm x 70 mm

Voltage: 3.7 V

Capacity (mAh, Ah): 3500 mAh

Max. charge voltage: 4.2 V

Max. charging current: 1700 mA

Terminal voltage: 2.75 V

Discharge current (max.): 5 A

Min. temperature: -20 °C

Max. temperature: +60 °C

Width: 19 mm

Height: 70 mm

Depth: 7.000 cm

(Ø): 18.5 mm

Weight: 55 g

Content: 1 pc(s)

Type: 18650 12.60 Wh

Rechargeable: Yes

Integrated surge protection: Yes

Factory colour: Silver

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1682008 Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

Information

Test Summary Report 1682008 Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

Conformity certificate

Conformity certificate 1682008 Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

Security datasheet

Security datasheet 1682008 Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

Warranty Terms

Warranty Terms 1682008 Ansmann 18650 12.60 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 3500 mAh 1 pc(s)

Description

Perfect protection thanks to Safety Board
The integrated safety board protects the cell from overcharging, overload, short-circuit or deep discharge. Thus, the battery is perfectly protected against incorrect handling, was a guarantee of a long life.
High energy level
Compared to conventional NiMH batteries, Li-Ion technology has almost twice the energy density with the same size.
Low weight, low self-discharge and high cycle stability
The ANSMANN 18650 Li-Ion battery is extremely long-lasting and can be charged up to 1000 times even under harsh conditions of use. Due to the very low self-discharge, the battery keeps its energy for a long period of time even when not in use. In addition, the weight of the Li-Ion cell is much lower than conventional battery technologies (e.g. NiCd/NiMH/PB) with the same performance.
Multiple application options
The high-quality lithium-ion battery from ANSMANN is ideal for use in modern devices such as LED flashlights, head lamps, e-cigarettes, laser pens etc. The cell has a capacity of 3500 mAh and is thus ideal for "power guzzlers" with hohem requirements. In addition, the battery can be used over a wide temperature range of -20°C to +60°C.

This text is machine translated.
