Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 16.80
3
4% = € 0.75
€ 16.05
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 16.80 / piece)
€ 23.52
-29 %
€ 16.80
plus VAT.
Li-Ion Battery 18650
Highlights & Details
- with protective circuit
- Capacity 2600 mAh
Technical specifications
- Charging according to the CC-CV-characteristic curve
- Size
18650
- Product type
Non-standard battery (rechargeable)
- Technology
Li-ion
- Dim
(Ø x H) 18.5 mm x 70 mm
- Voltage
3.7 V
- Capacity (mAh, Ah)
2600 mAh
- Max. charge voltage
4.2 V
- Max. charging current
1300 mA
- Terminal voltage
2.75 V
- Discharge current (max.)
4.4 A
- Min. temperature
0 °C
- Max. temperature
+60 °C
- Height
70 mm
- (Ø)
18.5 mm
- Weight
45 g
- Content
1 pc(s)
- Type
18650 9,36 Wh
- Rechargeable
Yes
- Integrated surge protection
Yes
- Factory colour
Silver
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1541492 Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
Information
Test Summary Report 1541492 Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
Conformity certificate
Conformity certificate 1541492 Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
Security datasheet
Security datasheet 1541492 Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
Warranty Terms
Warranty Terms 1541492 Ansmann 18650 9,36 Wh Non-standard battery (rechargeable) 18650 Li-ion 3.7 V 2600 mAh 1 pc(s)
Signal word
Danger
Description
The integrated Safety Board protects the cell from overcharge, overload, short circuit or discharge. Thus, the battery is perfectly protected against misuse, which guarantees a long service life.
Scope of delivery
- 1x 18650 Li-Ion rechargeable battery 2600 mAh
Hints
This text is machine translated.
